LevelOne FGP-1000 Quick Start Manual

FGP-1000 Version: 1
10-Port Fast Ethernet PoE Switch, 1 x Gigabit
RJ45, 1 x Gigabit SFP, 9 PoE Outputs
FGP-1000 is a 8-port 10/100Mbps Fast Ethernet Switch with Power over Ethernet (PoE) capability. With 8
dip switches, each PoE port can be manually set for On-Off control. FGP-1000 supports up to 30W on each
LAN port when the DIP switch is in the ON position . Using a LevelOne PoE repeater, it is possible to
extend the connection a further 100 meters, or even daisy-chain several PoE repeaters together for greater
distances. Dual 10/100Mbps ports can connect with other edge switches or NVR as uplink ports.
Key Features
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
- PoE on/off control per port by dip switches
- Simple Plug and Play installation
Specifications
System Specifications
Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3ab 1000BASE-T, Gigabit Ethernet
IEEE 802.3x Full-duplex Flow Control
