Sunwarm Air
Solar Energy Ventilation System
Installation and Maintenance Details for:
The Roofing contractor
The Building contractor
The Electrician
Nuaire Limited Western Industrial Estate Caerphilly United Kingdom CF83 1NA
T: 029 2088 5911 F: 029 2085 8444 E: info@nuaire.co.uk W: www.nuaire.co.uk
1
The EMC Directive
2004/108/EC
The Low Voltage
directive
2006/95/EC
10. 09. 13. Leaflet Number 671379
