Step 1: Erecting the Safety Cage
Front and Rear Rails
1. Hold the yellow cover on the end of an upper handrail using your thumb and
fingers, and push it towards the end of the rail. Hold it in this position while you
lift the end to unfasten it from its anchor point, see Figure 1.5.
2. Rotate the anchor point through 90 degrees to face the opposite side frames,
see Figure 1.6.
ROTATE
3. Rotate the rail end towards the opposite frame.
4. Extend the rail until you hear two clicks. This tells you that the 3-part rail has been
securely locked in its extended position. Carefully let the rail hang down from the
attached end.
Note. You should be able to see the ball-bearings from the locking mechanism
protruding from the side walls of the rail.
5. Repeat steps 1 to 4 for the other guardrails.
6. Lift one of the extended rails above its new anchor point on the opposite frame
and push down to lock in place.
7. Repeat for the other three rails to complete the erection of the Safety Cage,
Figure 1.7.
8. The Safety Cage can remain 'built' until the Tower is collapsed.
10
youngmangroup.com
1.5
1.6
1.6
