User Guide
Guía del usuario
Manuel de l'utilisateur
www.ergotron.com |
USA: 1-800-888-8458
888-60-508-W-00 rev. D • 09/19
SIM 90˚ Wall Mount
|
Europe: +31 (0)33-45 45 600
Benutzerhandbuch
ユーザーガイド
用户指南
|
China: 400-120-3051
Gebruikersgids
Guida per l'utente
Användarhandbok
|
Japan: japansupport@ergotron.com
1 of 13
Advertisement
Related Manuals for Ergotron SIM 90
Summary of Contents for Ergotron SIM 90
- Page 1 SIM 90˚ Wall Mount User Guide Benutzerhandbuch Gebruikersgids Guía del usuario ユーザーガイド Guida per l’utente Manuel de l’utilisateur 用户指南 Användarhandbok www.ergotron.com | USA: 1-800-888-8458 Europe: +31 (0)33-45 45 600 China: 400-120-3051 Japan: japansupport@ergotron.com 1 of 13 888-60-508-W-00 rev. D • 09/19...
- Page 2 M4x20mm 5.1(ID) x 10(OD) x 6mm M4x40mm 8.1(ID) x 16(OD) x 6mm M5x20mm M5 x 16mm M5x40mm 5.1(ID) x 10(OD) x 18mm M6x20mm M4 x 6mm M5 x 18mm 8.1(ID) x 16(OD) x 24mm M6x45mm M4 x 10mm M5 x 18mm 5.3(ID) x 16(OD) x 1.0mm M8x25mm 6.3(ID) x 14(OD) x 1.0mm...
- Page 3 CAUTION! DO NOT load above maximum weight capacities. Failure to comply with caution may result in instability leading to equipment damage or personal injury. < 115 lbs (52.2 kg) CPU must be a VESA compliant Thin Client CPU < 7 lbs <...
- Page 4 Attach Bracket to Wall Wood Concrete Madera Concreto Bois Béton Solide Holzbalkenträger Massivbeton Massief Houten Pilaren Beton Due montanti in legno massiccio Cemento 木 コンクリート 木质 水泥质 나무 콘크리트 Ø 3/8" (10 mm) Ø 3/16" (5 mm) WARNING: Ensure that the wall structure is capable of supporting four times the total weight of mounted equipment. Mounting to wall surfaces that do not meet this criteria may result in an unstable, unsafe condition which could lead to personal injury and/or property damage.
- Page 5 Wood Madera Bois Solide Holzbalkenträger Massief Houten Pilaren Due montanti in legno massiccio 木 木质 나무 Stud Finder Localizador de largueros de madera Stud Finder Auswahl von Montagematerial Positiebepaler balken Rilevatore di montanti スタッド ファインダー 螺栓探测器 스터드 파인더 Ø 3/16" (5 mm) 5 of 13 888-60-508-W-00 rev.
- Page 6 Concrete Concreto Béton Massivbeton Beton Cemento コンクリート 水泥质 콘크리트 Ø 3/8" (10 mm) > 3-1/8" (80 mm) WARNING: Mounting holes must be at least 3-1/8” (80mm) deep and must be located within solid concrete, not mortar or covering material. If you drill into an area of concrete that is not solid, reposition mounting holes until both anchors can be fully inserted into solid concrete! Anchors that are not fully set in solid concrete will not support the applied load resulting in an unstable, unsafe condition which could lead to personal injury and/or property damage.
- Page 7 M8 x 80mm CAUTION: DO NOT OVERTIGHTEN SCREWS! For solid concrete applications, torque screws to 60 in-lbs (6.8 N m). Screws must be fully seated in order to support applied load! The minimum torque for screws in solid wood studs is 60 in-lbs minimum (6.8 N m)while the maximum torque is 82 in-lbs (9.3 N m). Cuidado:: ¡...
- Page 8 200 mm 300 mm 400 mm 440 mm 500 mm 600 mm M5 x 16mm 600 mm 500 mm 440 mm 400 mm 300 mm 200 mm 8 of 13 888-60-508-W-00 rev. D • 09/19...
- Page 9 Attach Brackets to Display x < 600mm Find Appropriate Fasteners to Attach Your Display M6x20mm 5.1(ID) x 10(OD) x 6mm M4x20mm M6x45mm 8.1(ID) x 16(OD) x 6mm M4x40mm 5.3(ID) x 16(OD) x 1.0mm M5x20mm M8x25mm 5.1(ID) x 10(OD) x 18mm 6.3(ID) x 14(OD) x 1.0mm M5x40mm 8.1(ID) x 16(OD) x 24mm...
- Page 10 M4 x 6mm Tamper Proof Option Cut off tab. To remove CPU use a fl at head screwdriver to release tab. 10 of 13 888-60-508-W-00 rev. D • 09/19...
- Page 11 75 x 75 mm 100 x 100 mm M4 x 10mm 11 of 13 888-60-508-W-00 rev. D • 09/19...
- Page 12 M5 x 18mm M5 x 18mm 5-sided wrench llave pentagonal Clef Allen Inbusschlüssel 5-kantige sleutel Chiave a 5 lati 5 角レンチ 5角扳手 5면 렌치 90˚ Tilt – Forward and Backward Follow these instructions to tighten or loosen tension. Inclinación (adelante y atrás) Siga estas instrucciones para ajustar o afl...
- Page 13 For Warranty visit: www.ergotron.com/warranty For Service visit: www.ergotron.com For local customer care phone numbers visit: http://contact.ergotron.com Para acceder a la última versión de la Guía de instalación para el usuario, ingrese a www.ergotron.com Para Garantía, visite: www.ergotron.com/warranty Para servicio, visite: www.ergotron.com Para conocer los números telefónicos locales de atención al cliente, visite: http://contact.ergotron.com...
