NESTOR MARTIN TQH13 Instructions Manual

Hide thumbs Also See for TQH13:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
®
WOODBOX
TECHNOLOGY
INSTRUCTIONS
TQH13
TQH33
TQH43
TQ33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TQH13 and is the answer not in the manual?

Questions and answers

Related Manuals for NESTOR MARTIN TQH13

Summary of Contents for NESTOR MARTIN TQH13

  • Page 1 ® WOODBOX TECHNOLOGY INSTRUCTIONS TQH13 TQH33 TQH43 TQ33...

  • Page 2: Safety Requirements

    In the event of a problem, contact your installer directly. • Ask him to obtain the original NESTOR MARTIN parts. Beware of forgeries. To obtain a part, contact your installer/dealer in order to identify the order number of the part. Pass on this information to your installer and he will order the part directly from NESTOR MARTIN.
  • Page 3 INTRODUCTION INTRODUCTION We thank you for choosing a NESTOR MARTIN stove. This model is ofcutting edge design and complies with environmental standards. It is equipped with Woodbox technology which constitutes an important technical advance in the fi eld of wood fuel.

  • Page 4: Installation Instructions

    INSTALLATION INSTALLATION INSTRUCTIONS • Installation must conform to current building regulations. • The position of the appliance must respect the minimal distances in regards to combustible materials, shown on the descriptive plate. If necessary, install a wall protector. If the ground is not tiled, (i.e. fi tted carpet, parquet…) install a fl oor protector plate which extends out from under the appliance for at least 20cm at the back, 20cm at the sides and 50cm at the front.
  • Page 5 INTERCHANGING THE TOP/BACK FLUE OUTLETS By default your appliance is equipped for a top connection, but you also have the possibility of connecting it through the back. Procedure: Through the top Through the back metal stop gap Stop gap top fl ue outlet gasket Diaphragm gasket...
  • Page 6 INSTALLING THE MOTOR AND RECEIVER To install the motor and receiver, proceed as follows: Remove the control panel (2 screws) Magnet Strap Pull back the strap of the magnet then wedge the muff of the motor against the magnet. Place the receiver in its stand and fi x the stand in the two slots provided at the back of the appliance.

  • Page 7: Optional Extras

    OPTIONAL EXTRAS RANGE OF STAND Thanks to our range of quality stands, your stove has the possibility to become a practical, swivelling stove. Effectively, the stands are equipped with a bearing that allows them to be rotated 360°, giving you the chance to take full advantage of your wood fi re.
  • Page 8 LOG-STORE STAND This 6mm thick, lacquered-steel stand allows you to have a 360° swivelling stove due to the integrated bearings. It is equipped to receive a direct exterior air-intake system and a space to store wood logs. Dimensions in mm A [mm] B [mm] C [mm]...
  • Page 9 BENCH STAND The bench stand is adapted to hold the complete range of TQH stoves. It is equipped with a bearing so that your stove can move as well as having an exterior air-intake system. Dimensions in mm TQ/TQH 1700 OPTIONAL BEARINGS Thanks to the optional bearings, you have the possibility to mount your stove on different types of bases (stone, platform, bench stand…).
  • Page 10 SETTING UP ON THE STAND Tools required Accessories provided • Bearing bolt • Torx, cross-headed screwdriver or screw gun 19mm diameter latch key • M12 self-locking nut • • Size 8 Allen key (BTR) Number of people: 3 - 4 Procedure •...
  • Page 11 SETTING UP ON THE BENCH STAND Procedure • Place the bench stand in the prepared position. • Place the stove on the bench stand using a lift or sharing the weight between several people. • Unscrew the 2 fi xing screws of the control panel (Torx screws) and remove it. (See previous page). Diagram of the screw hole.
  • Page 12 CONNECTING AN EXTERIOR AIR-INTAKE Your appliance is pre-equipped to have a vertical exterior air duct through the ground. If you have purchased an optional base, you can also connect the duct through that. Vertical connection through the ground Horizontal connection through the stand Warning: for this kind of connection, install a ground This type of connection is only available with the purchase protection plate.

  • Page 13: Approved Fuels

    FUELS APPROVED FUELS Your appliance has been designed to burn the following approved fuels: Recommended solid fuels: beech wood, birch, oak, ash, hornbeam and wood from fruit trees. Non-recommended solid fuels: conifer, damp wood, chemically treated wood, shavings, wood pellets, coke.
  • Page 14 USER INSTRUCTIONS THE CONTROLS The appliance has two main controls: > the UPPER AIR FLOW control >the LOWER AIR FLOW control The two controls can be used together in a way to combine the two air fl ows to achieve optimum performance.
  • Page 15 Controls>different uses With the Woodbox combustion system, the air needed for the combustion can be brought from above or below the fi re according to the type of fuel used. A wood fi re must be fuelled from above (upper air supply), while a coal fi re is better fuelled from below (lower air supply).
  • Page 16 USING WOOD> LIGHTING MANUALY • Set the UPPER AIR SUPPLY to maximum • Set the LOWER AIR SUPPLY to maximum Tip: leave the door slightly open to stoke the fi re. It will increase the draw and allow an ember bed to be achieved. •...
  • Page 17 USING WOOD>ADDING LOGS To prevent smoke fumes from entering the room while adding wood and to ensure a rapid recovery of the hearth, do as follows: • Refi ll the appliance only when there is no longer an ember bed. •...

  • Page 18: Emptying The Ashtray

    EMPTYING THE ASHTRAY To avoid an overfl ow of ashes, empty the ashtray regularly. However, a fi ne layer of ash on the grate helps the combustion of the wood and retains heat. It is advisable to empty the ashtray when the appliance is not in use. To remove the ashes, drop them from the hearth into the ashtray through the grate with the tool provided.
  • Page 19 SELF-CLEANING OF THE WINDOW Your appliance is equipped with an integrated glass pane cleaning system (“Airwash”) which uses hot air to minimalize the marks on the glass pane. If you use a dry fuel, a large part of the tar deposited on the window will burn and disappear when the appliance is running at a high temperature.

  • Page 20: Maintenance

    For tough marks, it is better to touch up the paint with a paint designed for stoves (NESTOR MARTIN high temperature gloss paint) than to try to clean them. In the event of condensation, wipe the drops before they dry.
  • Page 21 REPLACING THE Glass pane To replace the glass pane • Lift the hearth door to remove it from the hinges. • Lay the door on a fl at surface. • Unscrew the eight nuts on the iron door that holds the glass pane.

  • Page 22: Garantie

    NESTORMARTIN. To make a warranty request for a faulty part, have the part replaced and send the faulty part to a NESTOR MARTIN distributor for inspection. If the fault is covered by the warranty, you will not be charged for the replacement part. The transport costs of the replacement part and returning the faulty part are your responsibility.
  • Page 23 C07100DB805...
  • Page 24 DIMENSIONS / AFMETINGEN / DIMENSIONI / DIMENSIONES / DIMENSIONS A [mm] B [mm] C [mm] D [mm] E [mm] F [mm] H [mm] TQH 13 D 150 182.5 TQ 33 D 150 TQH 33 D 180 TQH 43 D 180 C07100DB805...
  • Page 25 C07100DB805...
  • Page 26 C07100DB805...
  • Page 27 C07100DB805...
  • Page 28 C07100DB805...
  • Page 29 C07100DB805...
  • Page 30 C07100DB805...
  • Page 31 C07100DB805...
  • Page 32 ® WOODBOX TECHNOLOGY SOTO DE LA MARINA - CANTABRIA Apdo. de correos 208 SANTANDER C07100DB805_3 10/2016 C07100DB805...

This manual is also suitable for:

Tqh33Tqh43Tq33
