h.
The Convection Combo™ will operate in
Oven Mode with the timer either on or off. If
you want to time cooking, press the
numbered pads in the TIME portion of the
control panel to set the cooking time. The
time will appear in the Time Display . If you
enter the wrong number, press CLEAR to
erase the time from the display, and reenter
the time. Remember that the timer does not
control the unit in the Oven Mode.
i.
Open the door and slide the pan or pans
onto the pan racks in the cooking chamber.
If you are only using one pan, place it in the
middle position. Close the door.
j.
If the correct time has been set on the
timer, press the START pad. The colon [:]
between the numbers in the display will blink
and the time will count down the cooking
time. When the timer has counted down to
zero, it will sound a beeper. This sound will
continue until the door is opened or the
CLEAR pad is pressed.
k.
To stop cooking, take the pans out of the
oven using hot pads or oven mitts to protect
your hands from the hot pans. The unit will
continue heating to keep the chamber at the
set temperature until the temperature control
is reset, or the power is shut off.
WARNING
PANS AND INTERNAL PARTS OF THE OVEN
WILL BE VERY HOT. AVOID CONTACT WITH
HOT SURFACES.
l.
Opening the door during operation shuts off
power to the heaters and fan and stops the
timer, but it has no other effect on the
controls. When the door is closed, operation
continues. Note that cooking time will be
extended by the period the door was open.
3. Combo Mode
a.
If the unit is off, switch on the electric power
by pressing the ON touch pad. (If the
SERVICE light comes on when you turn on
the power, see the Troubleshooting section).
If the door is closed and the cooking
temperature is above 200
will begin to operate.
b. If the power is already on, and there is a
number in the time display window, press the
CLEAR touch pad one or more times to
reset the time to zero.
NOTE: You cannot change operating modes
while the timer is running
c.
The unit will power up in the mode of
operation in which it was last used. Because
of this, the indicator light for that mode will
be lit. If the unit is not already in the Combo
Mode, press the COMBO touch pad. The
COMBO light will come on and if the steam
generator is not already full, water will flow
into it and begin heating.
d. Use the Temperature Control Knob to set the
desired oven temperature between 220 and
o
575
F (105 to 300
appear in the temperature display window.
e. If the unit was recently used at a
temperature more than 15
than the temperature selected, the HOT and
WAIT lights will turn on. The unit can be
cooled quickly by leaving the door open or
following the Fast Cool procedure described
near the end of this section (Paragraph 5).
WHEN YOU OPEN THE DOOR ST AY AWAY
FROM ANY STEAM COMING OUT OF THE UNIT.
STEAM CAN CAUSE BURNS.
f.
The WAIT light will be on until the water in
the steam generator reaches boiling and the
air in the cooking chamber reaches the set
temperature. It will then turn off and the
READY light will come on to indicate that the
oven is at the desired temperature.
g. The unit will operate in Combo Mode with the
timer either on or off. If you want to time the
cooking, press the numbered pads in the
TIME portion of the control panel to set the
cooking time. The time will appear in the
Time Display Window. If you enter the
wrong number, press the CLEAR touch pad
17
OM-CC-G
o
o
F (93
C) the fan
o
C). The temperature will
o
o
F (-8
C) higher
WARNING
