GHP Group Dyna-Glo Delux Series Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Dyna-Glo
Propane Construction Heater
Description
Dyna-Glo Delux Model RMC-FA300DGD heaters are 300,000 BTU/Hr construction
TM
heaters. This heater uses propane gas for combustion, and electricity to run the
fan. It is primarily intended for temporary heating of well-ventilated buildings
under construction, alteration or repair. This heater should be utilized in sheltered,
well-ventilated areas, but never in occupied dwellings.
Specifications
Electrical Specifications
Model Electrical Input
RMC-FA300DGD 120 V, 60 Hz
General Specifications
Output Rating
Model BTU/Hr
RMC-FA300DGD 300,000
Hot Air Output
Model Approx. (CFM) Motor
FA300DGD RMC-FA300DGD 1800

Table of Contents

Description . . . . . . . . . . . . . . . . . . . . . . .1
Specifications. . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . 1
General Safety Information . . . . . . . . 1-3
Theory of Operation. . . . . . . . . . . . . . . .3
Installation. . . . . . . . . . . . . . . . . . . . . . 3-4
Ventilation. . . . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . . . 4-5
Maintenance . . . . . . . . . . . . . . . . . . . . 5-6
Storage . . . . . . . . . . . . . . . . . . . . . . . . . .6
Wiring Diagram. . . . . . . . . . . . . . . . . . . .6
Repair Parts Illustration
and Parts List . . . . . . . . . . . . . . . . . . . . 7-8
Air Quality Hazard Warning . . . . . . . . .9
Troubleshooting Chart . . . . . . . . . . . . .10
Warranty . . . . . . . . . . . . . . . . . . . . . . . .12
Unpacking
1. Unpack all materials used to protect
the heater inside of carton. Retain
plastic caps attached to exposed
fittings for use during storage.
www.ghpgroupinc.com
Delux
TM
Amperage
0.65
ANS Z83.7-2017 CSA 2.14-2017 CONSTRUCTION HEATER
Fuel
Propane Vapor Only
Minimum Supply
Pressure to Regulator
0.085 HP 25 PSIG (For purposes
1,720 RPM of input adjustment)
2. Remove heater, accessories and all
Page
hardware from carton.
3. Inspect all items for damage that may
have occurred during shipment.
WARNING
COMPLY WITH THE PRECAUTIONS AND
INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS
BODILY INJURY AND PROPERTY LOSS,
OR DAMAGE FROM THE HZARARDS OF
FIRE, EXPLOSION, BURN. ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/
OR ELECTRIC SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND
AND FOLLOW THE INSTRUCTIONS
SHOULD USE OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER
INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABELS, ETCETERA, CONTACT
THE MANUFACTURER.
General Safety Information
IMPORTANT: Be sure to read and
understand all cautions and warnings,
Printed in China
C US
Maximum Fuel
Consumption Ignition
13.9 lb/h Direct Spark, Interrupted
(6.3 kg/h)
Maximum Supply
Pressure to Regulator
Max Bottle Pressure
GENERAL HAZARD
WARNING
FAILURE TO
RMC-FA300DGD
Figure 1 - Model RMC-FA300DGD
Regulator
Outlet Pressure
7-10 PSIG
Size
L x W x H (Inches) RMC-RMC-
33.7 x 12.6 x 20.5
(85.6 x 32 x 52.1 cm)
before operating this heater. Keep
this instruction manual for future
reference, and use it as a guide to safe
and proper operation of the heater.
Various precautions appear throughout
this manual. Please review and pay
close attention to them. Below is an
explanation of the various levels of
caution required while operating this
heater.
DANGER Indicates an im minen tly
hazardous situation
which, if not avoided, WILL result in death
or serious injury.
WARNING Indicates a poten tially
hazardous situation
which, if not avoided, COULD result in
death or serious injury.
CAUTION Indicates a poten tially
hazardous situa tion
which, if not avoided, MAY result in minor
or moderate injury.
WARNING
FIRE, BURN,
INHALATION, AND
EXPLOSION HAZARD, KEEP SOLID
COMBUSTIBLES, SUCH AS BUILDING
IMLPF300DGD - KIO
PROFESSIONAL GRADE
