GHP Group Dyna-Glo Delux RA100NGDGD Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Dyna-Glo
Gas Radiant Heaters
Description
Dyna-Glo Delux Models RA100NGDGD and RA250NGDGD heaters are 50,000 to
100,000 and 250,000 BTU/Hr construction heaters. These heaters use natural gas for
combustion. They are primarily intended for temporary heating of well-ventilated
buildings under construction, alteration or repair. These heaters should be utilized
in sheltered, well-ventilated areas, but never in occupied dwellings.
CSA 2.14b-2009, ANS Z83.7b-2009 Construction Heater

Specifications

Fuel Consumption
Model BTU/Hr Maximum
RA100NGDGD 50,000 to 5.1 lbs
100,000
RA250NGDGD 250,000 12.8 lbs
Fuel Type – Natural Gas Only
Unpacking
1. Unpack all materials used to protect
the heater inside of carton. Retain
plastic caps attached to exposed
fittings for use during storage.
2. Remove heater, accessories and all
hardware from carton.
3. Inspect all items for damage that may
have occurred during shipment.
General Safety Information
Make sure you read and thoroughly
understand these safety and operating
instructions. Keep these instructions for
future reference. They are your guides
to safe and proper operation of this
heater.
Delux Natural
®
C US
Min. Gas Max. Gas
Supply Pressure Supply Pressure Pressure Gap
8" W.C. 14" W.C.
10 PSI 250 PSI
Ignition Type – Piezo (RA100NGDGD)
Pilot (RA250NGDGD)
Safety information appears throughout
this manual. Pay close attention to
them. Below are definitions for the
safety information listed throughout
this manual.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
situation which, if not avoided, COULD
result in death or serious injury.
situa tion which, if not avoided, MAY
result in minor or moderate injury.
vehicle use.
Printed in China
RA100NGDGD and RA250NGDGD
GHP Group, Inc.
8280 Austin Avenue
Morton Grove, IL 60053
Figure 1 – Models RA100NGDGD / RA250NGDGD
Manifold Ignitor
7.5" W.C. 0.19"
6 PSI 0.19"
Minimum Operating Temp. – -20°F (-29°C)
WarninG: Failure to comply with the
precautions and instructions provided
with this heater can result in death,
serious bodily injury, and property loss,
Indicates an or damage from hazards of fire,
im minen tly explosion, burn, asphyxiation, carbon
monoxide poisoning, and/or electrical
shock. Only persons who can
understand and follow these
instructions should use or service this
Indicates a poten­
heater. If you need assistance or heater
tially hazardous
information such as an instruction
manual, labels, etc., contact your local
manufacturer.
Indicates a poten­
tially hazardous
Consumer: Retain this manual for
future reference.
Not for home
or recreational
Rev. 2011-02-04
Size
Weight (Lbs) L x W x H (in.)
18.7 (heater) 16.3 x 16.3 x 29.8
30.8 (heater) 14.7 x 14.7 x 44.3
General
Hazard
