- Page 1 MCO Home Z-Wave Thermostat (2-pipe) SKU: MCOEMH8-FC...
-
Page 2: Quick Start
Quickstart This is a Thermostat for Europe. To run this device please connect it to your mains power supply. MCOHome Fan Coil Thermostat is a Z-Wave enabled device for indoor temperature control. To protect yourself and others from danger and to protect the device from damage, please read the safety information before using it. - Page 3 What is Z-Wave? Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section. Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is not in direct wireless range of the transmitter.
- Page 4 Thermostat is suggested to be installed indoor, a place with around 1.5m height above the floor where represents the average room temperature. It should be away from direct sunlight, any cover, or any heat source, to avoid false signal for temperature control. CAUTION: Cut off power supply at circuit breaker or fuse before installation to avoid fire, shock or death! Step 1: Remove the steel frame from the device, and secure it onto the junction box...
- Page 5 Devices can also be removed from a network. This process is called Exclusion. Both processes are initiated by the primary controller of the Z-Wave network. This controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is then performed doing a special manual action right on the device.
-
Page 6: Product Usage
Product Usage On/Off Setting When power on, thermostat will display “OFF”，press On/Off Button to enter working interface. When normal working, press On/Off Button to turn off the device, “OFF” displays and all outputs are off. Local Time Setting Press and hold (M) to enter local time setting. Touch M to switch among Week, Hour and Minute, and then press arrow down or arrow up to set the parameters of flashing item. - Page 7 Touch arrow down or arrow up to set local temperature value. Hold the buttons can set continuously. Press M , or wait for 15s to save and return to room temperature display. Fan Speed setting In normal display, press fan button to switch among the fan speed : Low, Medium, High, Auto ;...
- Page 8 Display Accuracy: 0.1°C Working Environment: 0~55°C; less than 95% RH (Non-condensation) Temperature Setting: 5~35°C (Adjustable) Dimension: 86* 86*42mm Hole Pitch: 60-65mm (86 Standard junction box) Z-Wave Frequency: 868.42MHz (EU) Quick trouble shooting Here are a few hints for network installation if things dont work as expected. 1.
- Page 9 Setting Description Celsius Fahrenheit Follow the main display Parameter 2: Upload temperature automatically Size: 1 Byte, Default Value: 3 Setting Description Upload the difference value only Timing upload mode only Upload the difference+timing upload mode Parameter 3: Upload temperature difference Size: 2 Byte, Default Value: 5 Setting Description...
- Page 10 IP Class IP 21 Voltage 230 V Load Device Type Thermostat Firmware Version 03.00 Z-Wave Version 04.21 Z-Wave Product Id 015f.0801.5102 Supported Command Classes Basic Sensor Multilevel Thermostat Mode Thermostat Operating State Thermostat Setpoint Thermostat Fan Mode ...
