Controls
1 LED Screen: Displaying information or functions
• MODE: Switch between USB / SD / Bluetooth / FM
*Hold down for two seconds to turn off/on | USB/SD must be plugged
• Play / Pause
• Stop
• Repeat
• Last
• Next
2 SD Card Slot: Use this to insert a SD Card with MP3 files
3 USB Connector: Use this to insert a USB flash drive with MP3 files
*
(USB works only with storage devices up to 32GB - Does not read mobile devices)
4 Bass: Use this to set the bass (low frequency)
5 Volume: Use this to set the master volume
6 Treble: Use this to set the treble (high frequency)
7 Echo: Echo level control
8 MIC/Guitar Volume: Use this to set the microphone/guitar volume level
9 MIC/Guitar input: Allows you to connect a microphone or an electric guitar using
a 1/4" banana plug or an XLR plug.
10 Line Inputs: (Composite) RCA or XLR, Use this to plug a external audio device.
Line input is a master device and can be played in any mode selected.
11 Line Out: Use this Composite (RCA) and/or XLR output to connect to another
active powered speaker.
12 AUX Input: Connect any media player using a 3.5mm auxiliary cable
Aux input is a master device and can be played in any mode selected
13 Power Switch: Use this to turn the unit On/Off
14 LED Switch: Use this to turn the front LED ring On/Off
15 Voltage Switch / Main supply input: Connect an IEC main power cable in order
to power the unit through electrical outlet connection. Use this to switch
between 110/240 volts. Please check the local main power supply before
connecting the unit.
16 Speaker Output: STC (Speaker Twist Connector) - Use to connect both
speakers together
17 Power LED: LED will illuminate when the power switch is in the on position.
18 Clipping: LED will blink when the input signal reaches saturation, reduce the input
level to eliminate saturation.
in for option to be selected.
(Cable Included)
www.alphasonik.com
(up to 32GB).
(*not included)
