- Page 1 Be Revolutionary. Be Alphasonik Professional High Power DJ Speaker System Operating Instructions Please Retain Manual for Future Use and Reference www.alphasonik.com...
-
Page 2: Our History
Today, the new Alphasonik is committed to pushing the envelope with regard to technology, quality and value. Our electronics feature audiophile parts and circuit topology designed to let the full musical experience come through, loud and clear. -
Page 3: Table Of Contents
Table of Contents Our History------------------------------------------------------------------------------------2 Table of Contents-----------------------------------------------------------------------------3 Introduction------------------------------------------------------------------------------------4 Specifications & Features -------------------------------------------------------5 (M912BT) Specifications & Features -------------------------------------------------------6 (M915BT) Input Wiring & Safety Overview---------------------------------------------------------7 Important Safety------------------------------------------------------------------------------8 Operations-------------------------------------------------------------------------------------9 Controls (Overview)-----------------------------------------------------------------10 - 11 Troubleshooting-----------------------------------------------------------------------------12 Disclaimer & Warranty--------------------------------------------------------------13 - 15 www.alphasonik.com... -
Page 4: Introduction
Introduction Thank you for purchasing this Alphasonik product. This manual contains important information about installation, set-up procedures and integrating your new Alphasonik product into your audio setup. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment. Before installing your new product, please read through the manual to fully understand the application. -
Page 5: (M912Bt)
68 Oz. HQ graphite y-30 magnet • 2.5” VC kapton 2-layer copper voice coil • High compression 2” titanium driver with horn tweeter • Frequency response: 46hz – 20khz • Sensitivity: 100db (±3dB) • Impedance: 4-ohm • Operation voltage: 110 - 240 volts (Switchable) www.alphasonik.com... -
Page 6: (M915Bt)
97 Oz. HQ graphite y-30 magnet • 3“ til 2-layer ccaw voice coil • High compression 2” titanium driver with horn tweeter • Frequency response: 40hz – 20khz • Sensitivity: 100db (±3dB) • Impedance: 4-ohm • Operation voltage: 110 - 240 volts (Switchable) www.alphasonik.com... -
Page 7: Input Wiring & Safety Overview
— Use appropriate mounting brackets to avoid bodily harm — Protect from any water or liquids — Never try to repair unit yourself — Keep out of reach of children, as there is high voltage and could cause injuries. www.alphasonik.com... -
Page 8: Important Safety
(i.e. sandbags) on the base of the stand to improve stability. - Be cautious of where you place the speaker system, certain frequencies will cause the unit to vibrate the cabinet and move from it’s original position. www.alphasonik.com... -
Page 9: Operations
Turn the VOLUME controls down and turn the POWER switch to the ON position. • This unit may be connected to another active Alphasonik speaker so that multiple speakers can be connected and playing at the same time from a single source. (Connect the XLR cable to the XLR output of the main speaker and connect the other end of the XLR cable to the secondary speaker’s XLR input. -
Page 10: Controls (Overview)
8. Auxiliary Inputs: (Composite) RCA, Use this to plug a external audio device or Connect any media player using a 3.5mm auxiliary cable (*cable not included) 9. Auxiliary Volume: Use this to set the Auxiliary Input volume level 10. Line Out: Use this XLR output to connect to another active powered speaker www.alphasonik.com... - Page 11 MEDIA CONTROLLER MP3 VOLUME MASTER 5-BAND GRAPHIC EQUALIZER CLIPPING POWER VOLUME VOLUME LINE LINE VOLUME 3.5mm MIC/LINE MIC/LINE LINE OUT HIGH POWER 2-WAY 12” ACTIVE PA SPEAKER SYSTEM W/ DIGITAL AMPLIFIER Watts Watts www.alphasonik.com POWER AC110-240V...
-
Page 12: Troubleshooting
Troubleshooting In the event that your Alphasonik speaker appears to require service, we ask that you first do a little troubleshooting to determine if the problem is actually the speaker, or a problem located in the area where the speaker was connected. -
Page 13: Disclaimer & Warranty
The warranty is applicable to the original purchaser, and is non-transferable. This warranty specifically covers woofer & tweeter defects only (excluding Burnt-out Voice Coils). You must provide a receipt from an Authorized Alphasonik Dealer that shows the location of purchase, price paid, and date of purchase. - Page 14 - Any product that is new, and/or found to be in working condition - Burned Out Voice Coils caused by Neglectful Operation - L.E.D. indicators on electronics (Alphasonik will only replace L.E.D.(s) found to be defective at the time of purchase).
- Page 15 Alphasonik. Any product found to have no manufacturer defect will be returned to the sender at their cost.
- Page 16 Be Revolutionary. Be Alphasonik www.alphasonik.com...
