- Page 1 Cinco 5-way coin sorter Operating Manual Cod. DMSA5C0001.2EN Rev. 1.2 19 – 05 – 2016...
- Page 3 GUIDE TO THE SYMBOLS IN THE MANUAL The following symbols are used in this manual to facilitate its under standing: Important information Read carefully before use Warning!
- Page 4 5-way coin sorter Cinco - Operating Manual DECLARATION OF CONFORMITY THE MANUFACTURER: SUZOHAPP Antonie Van Leeuwenhoekstraat 9 3261 Oud-Beijerland LT NL DECLARES That the product: CINCO TYPE: 5-way coin sorter TRADEMARK: Comesterogroup Complies with that foreseen by the following EU directives,...
- Page 5 Risks deriving from using the machine If maintained in good operating conditions and installed correctly (according to the instructions of this manual), the machine does not pose any danger for the operator. Personnel in charge of charging the dispensers, switching the device on and of servicing the machine must be aware that all movable parts, doors, cash point, can cause injuries if not properly handled;...
- Page 6 5-way coin sorter Cinco - Operating Manual Caution: • Make sure that the distribution line is sized according to the intensity of the current absorbed by the machine • Set up the grounding system before connecting the machine and its accessories. Hazards during machine maintenance Electrical hazards : direct contact with live parts within the electrical cabinet.
- Page 7 GENERAL WARRANTY Please read the following carefully to understand the general warranty conditions for this product. ART. 1 - Scope of application These general terms and conditions shall apply to all the goods and services provided by our company. Placed orders shall imply the full and unconditional acceptance of these general terms and conditions of sale.
- Page 8 Malfunctioning of the machine due to the software not being upgraded is not considered a defect. SUZOHAPP is not obliged in any way to upgrade the software free of charge or upgrade the mechanical components which may be necessary due to new coins or banknotes being introduced by the Italian and European authorities, when repairing a product that is covered by the warranty.
- Page 9 Any dispute shall be resolved by the Court of Milan. Dear customer, thank you for choosing a SUZOHAPP product; by following the instructions of this manual carefully you will be able to appreciate and be satisfied by its quality. Please read the operation and maintenance instructions carefully, in compliance with the safety provisions, before using the machine and store this manual for future reference.
-
Page 10: Table Of Contents
5-way coin sorter Cinco - Operating Manual Table of contents 1. Introduction ............................11 2. Product presentation ........................11 2.1 Accessories ................................... 12 3. Warnings ............................. 13 4. Unpacking ............................13 5. Connections ............................13 5.1 ccTalk Mode .................................. 14 5.2 Parallel Mode ................................ -
Page 11: Introduction
2. Product presentation SUZOHAPP has completed its range of coin sorters with a new 5-way sorter with a special focus on versatility. Only two versions are available, using the same sorter unit. 5-way sorter... -
Page 12: Accessories
5-way coin sorter Cinco - Operating Manual 2.1 Accessories A series of optional accessories makes it possible to satisfy the requirements of different types of use and installation. Funnels Top Funnel (H: 20,5 mm) Article code 1068-25-0021-A Medium Funnel (H: 11,5 mm) Article code 1068-25-0022-A Low Funnel (H: 4,5 mm) -
Page 13: Warnings
3. Warnings Read this manual carefully before use. Knowledge of the information and instructions contained in this manual is fundamental to use the product correctly. Check upon receipt that the package and the product have not been damaged during transport. Take care with the electrical connections. -
Page 14: Cctalk Mode
5-way coin sorter Cinco - Operating Manual • ccTalk applications (the coin mechanism guides the sorter) • Parallel applications (the machine guides the sorter) The table below (which also appears on the sorter) indicates which connectors to use on the basis of the coin mechanism and how the sorter is used. The names of the connectors refer to the information appearing on the coin sorter, as shown in the image below. -
Page 15: Parallel Mode
PRG, as shown below. The coin mechanism will control a Comestero Cinco 5-way coin sorter without a jumper. If a jumper is inserted in the centre, as shown, the coin mechanism will be able to operate another manufacturer’s coin sorter. -
Page 16: Care And Maintenance
5-way coin sorter Cinco - Operating Manual NOTE: The outputs 2 and 5 are not suitable for coins with diameters and thicknesses, respectively, lower than 22,25 mm and 2,14 mm. This involve for example that, in the Euro area, you can not send on paths 2 and 5 coins with denomination lower than 0,20 Euro. -
Page 17: Technical Service
Periodically check the condition of the apparatus’ surfaces, paying special attention to areas which can represent a hazard to the user under normal conditions of use. 7. Technical service In the event of an anomaly or malfunction, contact SUZOHAPP Post- Sales Assistance Service at : (+39) 02 95781111. 8. Technical data Power suppl y [Vdc] : 12 ÷... - Page 18 5-way coin sorter Cinco - Operating Manual...
-
Page 19: Appendices
At the end of its life the product must be decommissioned and sent to a disposal centre. Remove the machine from its installation place, empty all coins and remove the power cable. Contact SUZOHAPP to collect the decommissioned machine. Call the following telephone number: +39 02/95781111. - Page 20 5-way coin sorter Cinco - Operating Manual • These machines or their parts are potentially harmful for the environment and human health if used incorrectly or if not disposed of pursuant to the present procedure, due to some substances being present in the electronic components •...
- Page 21 With the exceptions set out by article 5 section 2, everyone that after July 1, 2006 launches on the market WEE containing substances listed in article 5, section 1 or further substances identified pursuant to article 18, section 1, will incur a monetary sanction of Euro 50 to Euro 500 for each device that enters the market or of Euro 30,000 to Euro 100,000...
- Page 22 5-way coin sorter Cinco - Operating Manual...
- Page 24 F +1 (800) 593 4277 F +61 3 9763 7265 Info.nl@suzohapp.com info@suzohapp.com info@suzohapp.com.au suzohapp.com For more information: SuzoHapp Netherlands B.V. Antonie Van Leeuwenhoekstraat 9 3261 LT Oud-Beijerland - The Netherlands Phone: (+31) 186 64 33 33 - Fax: (+31) 186 64 33 32...
