Halsey Taylor Owners Manual
Non-Refrigerated Freeze Resistant Fountains
OVLEBPFR
Installer
Halsey Taylor Fountains are among the easiest to install Fountains on the market
today. To assure you install this model easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR
INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL AND OTHER
APPLICABLE CODES. After installation, leave these instructions with the Fountain
for future reference. This Freeze Resistant Fountain(s) is shipped in two separate
cartons. The second carton(s) contains the Freeze Resistant Package(s) HTFRB1
that are installed on an interior heated wall. The interior space must maintain a
minimum temperature of 50° F (10° C). Refer to the Freeze Resistant Package for
the rough-in dimensions for installation.
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM
THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN
ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE
WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN
FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE
FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
OVLEBPFR, OVLSBPFR, OVLSEBPFR
OVLSBPFR
IMPORTANT
PAGE 1
OVLSEBPFR
97811C (Rev. G - 09/17)
Advertisement
Related Manuals for Halsey Taylor OVLEBPFR
Summary of Contents for Halsey Taylor OVLEBPFR
- Page 1 OVLSBPFR OVLEBPFR Installer Halsey Taylor Fountains are among the easiest to install Fountains on the market today. To assure you install this model easily and correctly, PLEASE READ THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL AND OTHER APPLICABLE CODES.
- Page 2 OVLEBPFR, OVLSBPFR, OVLSEBPFR OVL - EBPFR/SBPFR/SEBPFR COOLER INSTALLATION The freeze resistant package must be mounted on an interior wall in a heated area. The room temperature of the interior heated area must be 50° F (10° C) or higher. The freeze resistant package may be surface or recessed mounted. If recess mounted the surface of the cover must be flush with the interior wall surface.
- Page 3 OVLEBPFR, OVLSBPFR, OVLSEBPFR PAGE 3 97811C (Rev. G - 09/17)
- Page 4 OVLEBPFR, OVLSBPFR, OVLSEBPFR 97811C (Rev. G - 09/17) PAGE 4...
- Page 5 OVLEBPFR, OVLSBPFR, OVLSEBPFR PAGE 5 97811C (Rev. G - 09/17)
- Page 6 OVLEBPFR, OVLSBPFR, OVLSEBPFR 97811C (Rev. G - 09/17) PAGE 6...
- Page 7 OVLEBPFR, OVLSBPFR, OVLSEBPFR PAGE 7 97811C (Rev. G - 09/17)
- Page 8 OVLEBPFR, OVLSBPFR, OVLSEBPFR 97811C (Rev. G - 09/17) PAGE 8...
- Page 9 OVLEBPFR, OVLSBPFR, OVLSEBPFR PAGE 9 97811C (Rev. G - 09/17)
- Page 10 OVLEBPFR, OVLSBPFR, OVLSEBPFR 97811C (Rev. G - 09/17) PAGE 10...
- Page 11 OVLEBPFR, OVLSBPFR, OVLSEBPFR PAGE 11 97811C (Rev. G - 09/17)
- Page 12 OVLEBPFR, OVLSBPFR, OVLSEBPFR CABLE SHEATH ADJUSTMENT To Increase Free Play To Reduce Free Play FIG. 11 FIG. 12 FIG. 13 97811C (Rev. G - 09/17) PAGE 12...
- Page 13 OVLEBPFR, OVLSBPFR, OVLSEBPFR FIG. 14 SEE FIG. 13 SEE FIG. 8 FIG. 15 Installing Back Panel: When installing back panel assy. (Item 25) with MPW (Mounting Plate), at- tach channel braces as shown above. Remove the protective backing from the tape installed on the braces.
- Page 14 OVLEBPFR, OVLSBPFR, OVLSEBPFR 14, 15 FIG. 18 97811C (Rev. G - 09/17) PAGE 14...
-
Page 15: Parts List
OVLEBPFR, OVLSBPFR, OVLSEBPFR PARTS LIST ITEM PART NO. DESCRIPTION 27688C Bottom Cover (OVL-S) 27689C Bottom Cover (OVL-E) 50595C Bushing - Snap 51546C Bubbler 100322740560 Gasket - Black 1000002143 Kit - Drain/Strainer Assy (includes Plug/ Strainer/Rings/Nut/Plug/Gasket) 96884C Kit - Basin & Liner...
