Summary of Contents for Dali SUB P-10 DSS
- Page 1 ENGLISH MEGALINE EUPHONIA HELICON MK2 MENTOR IKON® LEKTOR® CONCEPT N SUBWOOFER TABLE 1 DALI SUB P-10 DSS P-10 DSS MANUAL Speaker(s) pr. carton FIGURE 1 FIGURE 2 FIGURE 3 20 Hz 100 Hz Movie Music DALI Denmark +45 9672 1155...
- Page 2 DALI P-10 DSS SUB IR REMOTE CONTROL CINEMA PHASE HIFI FREQ FIGURE 6 TABLE 2 - DALI SUB P-10 DSS TECHNICAL SPECIFICATIONS MEMORIES DALI SUB P-10 DSS Frequency Range [+/- 3] dB [Hz] 24 - 250 Input Impedance [kohm] Maximum SPL [dB]...
- Page 3 CONTENTS ENGLISH...
- Page 4 The lightning flash within an equilateral triangle is C A U T I O N intended to alert you to the presence of non insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute an electric shock to persons.
-
Page 5: Table Of Contents
CONTENTS 1.0 INTRODUCTION 2.0 UNPACKING 3.0 POSITIONING 4.0 CONNECTION 5.0 INSTALLING AND ADJUSTING 6.0 RUNNING-IN 7.0 OVERLOADING 8.0 MAINTENANCE 9.0 DISPOSAL 10.0 AMPLIFIER BACK PLATE 11.0 TECHNICAL SPECIFICATIONS... -
Page 6: Introduction
Please be aware, that spikes may damage the floor. 4.0 CONNECTION DALI SUB P-10 DSS has a built-in power amplifier with an active crossover. The inputs of the subwoofer amplifier should be connected to your stereo or surround sound (pre-) amplifier/ receiver using a RCA cable (sold separately). - Page 7 “ON”. 4.1 STEREO CONNECTIONS If you want to use DALI SUB P-10 DSS in a stereo setup, your stereo (pre-) amplifier/receiver should have either a set of stereo RCA line outputs or a mono RCA line output available (please refer to the instruction manual of your stereo (pre-)amplifier/receiver).
-
Page 8: Installing And Adjusting
4.3 USING TWO DALI SUB P-10 DSS SUBWOOFERS In most cases you will achieve excellent results with one DALI SUB P-10 DSS. Use of two subwoofers is possible as a no-compromise stereo solution, or for reproduction of very powerful sound pressures in a stereo or surround setup in larger rooms. - Page 9 When installing the DALI SUB P-10 DSS in a surround sound system, we recommend selecting a fixed level on the subwoofer and adjusting the subwoofer output using the surround (pre-) amplifier’s/ receiver’s setup function.
- Page 10 5.3.2 USING LFE INPUT When connecting your DALI SUB P-10 DSS to smaller speakers, e.g. the DALI EPICON 2, we recommend a crossover point of approximately 80 Hz. This must be entered in the menu system of your (pre-) amplifier. You might need to enter the ‘small’ setting when selecting type of front speakers in the AV receiver menu.
- Page 11 5.7 REMOTE CONTROL (see Figure 4) A) Standby ON/OFF Press to toggle between the two states (ON/OFF switch on the rear panel must be set to ON). NOTE: When the AUTO/MANUAL switch is set to AUTO, the subwoofer cannot be turned off with signal on the inputs.
-
Page 12: Running-In
Use normal music for running-in the subwoofer. 7.0 OVERLOADING If DALI SUB P-10 DSS is overloaded, the built-in safety circuit will power down the subwoofer. The subwoofer will power on again when the temperature of the built-in amplifier is within safe working range. -
Page 13: Amplifier Back Plate
However, none of them tell you anything useful about how a subwoofer really sounds. Only your ears can decide whether one subwoofer sounds better than another. Like all our speakers, DALI SUB P-10 DSS is designed to reproduce music as honestly as possible.
