- Page 1 CAUTION – READ THESE INSTRUCTIONS BEFORE USING THE MACHINE User instructions MW240, MW340, MW340/PUMP,MW440/PUMP Multipurpose floor cleaning machines 03-5977-0000 Issue 5 12/08 http://www.truvox.com/Products/Scrubber_Dryers/Multiwash...
-
Page 2: Table Of Contents
Contents Page 1. Product information .................... 3 1.1. Important safety instructions ..............3 1.2. Guidelines for the operator ..............3 1.3. Electrical connection ................3 2. Knowing your machine ................... 4 3. Working Principle ..................5 4. Preparing for use ................... 5 5. -
Page 4: Product Information
IMPORTANT READ THESE INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE REFERENCE 1. Product Information 1.2 Guidelines for the operator • Please pass all safety instructions on to other Operators must be fully trained in accordance persons operating this machine. with these instructions, able to perform routine upkeep of the machine and correct selection of The floor cleaning machines are designed for use on brushes. -
Page 5: Knowing Your Machine
2. Knowing your machine NOTE: MWXXX refers Standard model & MWXXX/PUMP refers Pump model XXX refers to machine width 240 / 340 / 440 mm If you have purchased Pump model please refer Fig. b, Fig. c, Fig. e & Fig. g(for Fig.g see page 6) If you have purchased Standard model please refer Fig. -
Page 6: Working Principle
Warning! Since the bottom handle is spring 3. Working Principle loaded, care must be taken when removing the hook to avoid sudden springing back leading to possible injury to personnel. 5. Assembly 1. Insert the two tubular handles into the bottom handle and secure them using knob (2 off) by tightening lightly. -
Page 7: Brush Selection Guide
6. Brush Selection Guide Transport/Working Mode Control Slide this knob to TOP position Type of floor First time Maintenance (Working Mode) to operate the cleaning Cleaning machine. Slide this knob to All natural stone Standard Soft BOTTOM position to move the floors, Ceramic, machine and park the machine. -
Page 8: Operating The Machine
9. Operating the machine 4. Pull the machine backwards in the same track, Before the washing operation starts but without discharging any liquid. When you reach the starting point, change the track and repeat steps 2 through 4. When you are Warning! Pre-sweep the floor to remove debris changing the track allow some overlap with the before using the machine... -
Page 9: Maintenance
11. Maintenance 12. Accessories Transport Trolley The simply fitted trolley provides for ease of Warning! Before undertaking any maintenance movement when transporting the machine. operations or adjustments switch off the machine and unplug from the electrical supply. Warning! Empty all liquid from the machine before using the transporter. -
Page 10: After Sales Service
13. After sales service Should you require after sales service please contact the supplier from whom you purchased the machine, who will arrange service. Repairs and servicing should only be performed by trained staff. Improper repairs can cause considerable danger to the user. -
Page 11: Electrical Diagram
14. Electrical Diagram... -
Page 12: Technical Specification
1 year 1 year 1 year Other voltages available Model Main supply Power (W) Brush speed (rpm) MW340/Pump 220 VAC + 6%, 60Hz, 1050 Single Phase MW340/Pump 110 VAC + 6%, 50Hz, 750 + 26 Single Phase MW340/Pump 110 VAC + 6%, 60Hz,... - Page 13 Make Type Floor cleaning machine Model MW240, MW340, MW340/PUMP and MW440/PUMP Serial Number: Year of Construction: 2006 has been manufactured using the following transposed harmonized European Standards and technical specifications. BS EN 60335-1 AND BS EN 60335-2-67, EMC: EN 55014-1, EN 61000-3-2, EN 61000-3-3, EMF: EN 50366, and...
