- Page 1 User instructions Orbis Compact – OB28240 Rotary floor cleaning machine CAUTION - READ THESE INSTRUCTIONS BEFORE USING THE MACHINE 03-8069-0000 Iss.1 09/06...
- Page 2 Fig 1 Fig 2 Fig 3 Fig 4...
-
Page 3: Table Of Contents
Contents Page 1 Product information ..............4 1.1 Important safety advice ..............4 1.2 Guidelines for the operator ............. 4 1.3 Transporting the machine ............... 4 2 Preparing for use ................5 2.1 Electrical connection ............... 5 3 Controls ..................... 5 3.1 Fitting pads ................... -
Page 4: Product Information
IMPORTANT READ THESE INSTRUCTIONS CAREFULLY AND RETAIN FOR FUTURE REFERENCE 1 Product information 1.2 Guidelines for the operator • Operators must be fully trained in the use These floor cleaning machines are designed of the machine in accordance with these for the scrubbing and polishing of hard floors instructions, able to perform user and/or shampooing of carpets in indoor... -
Page 5: Preparing For Use
6 - Solution feed lever Operates flow valve in solution tank (if 2 Preparing for use fitted). - Pull lever to release solution. - Release lever to stop flow 2.1 Electrical connection Cable winder Before connecting the machine to the power Used to hold supply cord in place on supply, check that your supply voltage handle when machine is not in use. -
Page 6: Starting The Machine
4.4 Fitting the solution tank 4.1 Starting the machine NOTE - The solution tank is supplied as an • Fully unwind the supply cord from the optional accessory item, complete with handle and plug into a convenient socket attachments and fitting instructions. outlet. -
Page 7: Maintenance
This is usually this could result in transit damage. caused by the stickiness of the pad or 3. Neither Truvox nor its distibutor shall be floor. Turn the cleaning pad over or if both liable for any incidental or consequential sides are dirty replace with a clean pad. -
Page 8: Technical Specification
Note1: Always use high quality 28cm pads. Use of poor quality or incorrect size pads will affect machine performance. Always replace pads when they are worn or dirty. IMPORTANT : Genuine accessories are only available from authorised Service Agents or Truvox Customer Service Dept. -
Page 9: Fault Diagnosis
11 Fault diagnosis The following simple checks may be performed by the operator. Trouble Reason Remedy Machine not working, neon - Lack of voltage/electrical - Check fuse *, supply cord, plug indicator not lit. supply. and socket outlet. Machine not working, neon - Switch interlock incorrectly - Check operating procedure in indicator lit. -
Page 10: Declaration Of Conformity
12 Declaration of conformity EC Declaration of conformity We, Truvox International Ltd. Third Avenue Millbrook Trading Estate Southampton SO15 0LE England declare that the machinery Make Rotary floor cleaning machines Type Orbis Model OB28240 Serial Number from 000001 Year of Construction :... - Page 12 ___________________________________________________________________________ Truvox International Limited, Third Avenue, Millbrook, Southampton, Hampshire SO15 0LE England Tel: +44 (0) 23 8070 2200 Fax: +44 (0) 23 8070 5001 e-mail: truvox@truvox.com Web: www.truvox.com...
