Fig. 8.

8. TROUBLESHOOTING

In case of emergency, please, use the troubleshooting methods shown
in tables. If it is impossible to solve problems with these methods, apply
to the service center.
Failures and their possible reasons:
Problem
• Make sure the dehumidifier s plug is pushed completely into
the outlet.
Unit does not start • Check the house fuse/circuit breaker box.
• Dehumidifier has reached its preset level or bucket is full.
• Bucket is not in the proper position.
• Did not allow enough time to remove the moisture.
• Make sure there are no curtains, blinds or furniture blocking
the front or back of the dehumidifier.
Dehumidifier does • The humidity selector may not be set low enough.
not dry the air as it • Check that all doors, windows and other openings are
should securely closed.
• Room temperature is too low, below 5 C(41 F).
• There is a kerosene heater or something giving off water
vapor in the room.
The unit makes a • The air filter is clogged.
loud noise when • The unit is tilted instead of upright as it should be.
operating • The floor surface is not level.
8
www.timberk.com • Electric drier for changing of air humidity
What to check
Problem
Frost appears on the This is normal. The unit has Auto defrost feature.
coils
Hose to connector or hose connection may be loose.
Water on floor Intend to use the bucket to collect water, but the back
drain plug is removed.
Power indicator light Temperature sensor or Humidity sensor error. Unplug the unit
flashes at 5 times per and plug it back in.If error repeats, call for service.
second.

9. TRANSPORTATIOM AND STORAGE

Temperature
requirements*
Transportation and
storage
Humidity
requirements*
We are exploring new technologies and we constantly improving the
quality of our products. That's why specifications, design and accessories
are subject to change without any specific notice.
* This product must have storage in dry, well-ventilated space of warehouse at the
temperature not lower than -30°

10.SERVICE LIFE

Service life of the appliance is 10 years provided that the respective
installation and operation rules are observed.
Date of the conditioner manufacture is shown in a serial number of the
device. For more details, please, ask a shop assistant.

11. UTILIZATION RULES

Upon expiration of the service life, the appliance should be utilized in
accordance with norms, regulations and procedures effective in the
place of utilization.
What to check
From -30° to +50°
From 15% to 85%
(without a condensate)
