Casters(Install at four points on the bottom of unit)
• Casters can only move laterally.
• Do not force casters to move over carpet, nor move the unit with water
in the bucket. (The unit may tip over and spill water.)
NOTE:
Casters is optional,some models without.
5. DELIVERY SET
Completed set of the appliance:
Appliance (air drier) - 1 piece
Appliance packing - 1 piece
User manual and Guarantee slip -1 piece
6. APPLIANCE CONTROL
Fig. 3.
Indicator lights
1. Power on indicator light(green)
2. Continuous operation on indicator light(green)
3. Bucket full indicator light(red)
4. Display
Shows the set % humidity level while setting, then shows the actual
(+5% accuracy) room % humidity level.
Error Codes:
E1- Humidity sensor error--Unplug the unit and plug it back in. If error
repeats, call for service.
E2- Temperature sensor error-- Unplug the unit and plug it back in. If
error repeats, call for service.
Protect Codes:
P1- Unit is defrosting – Allow the unit to automatically defrost. The
portect will clear after the unit self defrosts.
P2- Bucket is full or bucket is not in the right position – Empty the bucket
and replace in the right position.
Control pads
5. POWER Pad
Press to turn the dehumidifier on and off.
6. Humidity Set Control Pads
The humidity level can be set within a range of 35%RH(Relative Humidity)
to 80% RH(Relative Humidity) in 5% increments. For drier air, press the
pad and set to a lower percent value(%). For damper air, press the pad
and set to a higher percent value(%).
7. Continue Pad
Select for the dehumidifier to operate continuously for maximum
dehumidification until the bucket is full. The Humidity set control pads
cannot be used when. Continuous operation is on.Press this pad again
to cancel Continuous operation.
www.timberk.com • Electric drier for changing of air humidity
5
