Figure 3: DS2-RPC Menu Rev F0.15
DS-RPC Power Control
(C) 1997 by BayTech
Rev. F0.15
Circuit Breaker: On
1)...Outlet 1 : On
2)...Outlet 2 : On
3)...Outlet 3 : On
4)...Outlet 4 : On
DS-RPC>
Type 'off' / 'on' / 'reboot' at prompt and should get the following:
'off' = Figure 3; 'on' = Figure 4; 'reboot' = Figure 5
NOTE: The reboot option has a 10-second count
down before the outlets turn back on
Figure 7: Configuration Menu
1)...Change Password
2)...Change Outlet Name
3)...Enable/Disable Confirmation
4)...Enable/Disable Status Menu
X)...Exit
Enter Request:
DS4(A)­RPC Controller Quick Start
Setup the HOST module configuration first, before continuing.
1. If you get only a blinking cursor Press 'Enter'. If still get only a blinking cursor, Type 5 semi-
colons (;), The Attention Character will not echo on the screen. There is a one second delay before
the menu is displayed. You should see a menu similar to (Figure 9).
2. Type "C" at the prompt and press 'Enter'.
3. Type the number for the 'DS-RPC' and press 'Enter', (Figure 10).
4. Type "1" for Manage Users and press 'Enter'. (Figure 11)
5. IMPORTANT: the first user added will be the ADMIN user. Type 'A' and press 'Enter', (Figure
12) Type a name for the admin user. Type the number of the user, just added. Add the outlets.
6. Press 'Enter' until you get to the Host module menu (Figure 9).
At this point you have enough basic configurations needed to operate the RPC part of the DS-RPC unit.
Figure 8: Password
Enter Current Password: ****
Enter new Password:
Re-Enter new Password:
Figure 4: Outlets ON
DS-RPC>off
Turn Off All Outlets (Y/N)?
Figure 5: Outlets Off
DS-RPC>on
Turn On All Outlets (Y/N)?
Figure 6: Outlets Reboot
DS-RPC>reboot
Reboot All Outlets (Y/N)?
"9-0 count down"
