BayTech DS-RPC Quick Start Manual

Data switch-remote power control
Hide thumbs Also See for DS-RPC:

Advertisement

Quick Links

2019
Data Switch‐Remote Power Control
Quick Start (DS‐RPC)
 Copyright 2019
Bay Technical Associates, Inc
10/1/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-RPC and is the answer not in the manual?

Questions and answers

Summary of Contents for BayTech DS-RPC

  • Page 1 2019  Data Switch‐Remote Power Control Quick Start (DS‐RPC)  Copyright 2019  Bay Technical Associates, Inc  10/1/2019 ...
  • Page 2: Table Of Contents

    Table of Contents    CABLING  ......................................  3   RJ‐45   ......................................  3   ABLE    ........................................  4 DAPTERS   SERIAL SETUP ....................................  5   QUICK START: DS‐RPC  ..................................  5   DS2‐RPC   ................................  5   ONTROLLER  UICK  TART   DS4(A)‐RPC   ...............................  6  ...
  • Page 3: Cabling

    Handshake In. –12V when not used Signal Ground Used as a handshake line to enable/disable the receiving of characters. Adapter signals Listed are the pin specifications for the BayTech cable and adapters and the terminal COM ports: Serial 1: Port Pin out Table Signal RS-232...
  • Page 4: Adapters

    RJ08X007 Standard Rollover Cable – RJ45 to RJ45 Serial 2: RJ08X007 Pin out Serial 3: RJ45 Receptacle & Plug Adapters  Serial 4: 9FRJ45PC-1 Adapter Pin Out (Use with RJ08X007 Cable and B/C switch in “B”)
  • Page 5: Serial Setup

    For those Administrators who have requested the bare minimum for this type of equipment, follow these steps exactly. If this is a new unit shipped directly from Baytech, follow the steps. If this is a previously own unit, perform a factory reset to clear out any users and passwords still in the unit.
  • Page 6: Ds4(A)-Rpc Controller Quick Start

    12) Type a name for the admin user. Type the number of the user, just added. Add the outlets. 6. Press ‘Enter’ until you get to the Host module menu (Figure 9). At this point you have enough basic configurations needed to operate the RPC part of the DS-RPC unit.
  • Page 7 ....4 Enter Request :3 DS-RPC ....5 Configure.......C Status......S Unit Reset......RU Logout......T Enter Request :c Figure 11: DS-RPC Configuration Menu 1)...Manage Users Figure 12: Add User Menu 2)...Change Outlet Name 3)...Enable/Disable Confirmation --------------------------------------------- 4)...Enable/Disable Status Menu User Assigned Outlets 5)...Change Unit ID 6)...Change Alarm Threshold...
