Speed controller
CDT(E) E
OPERATION MANUAL
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDTE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLAUBERG CDTE Series

  • Page 1 Speed controller CDT(E) E OPERATION MANUAL...
  • Page 2 CDT(E) E I n t r o d u c t i o n р . 3 CONTENTS S a f e t y r e q u i r e m e n t s р . 3 O p e r a t i n g r e q u i r e m e n t s р...
  • Page 3: Safety Requirements

    CDT(E) E The present operation manual consisting of the technical details, operating instructions INTRODUCTION and technical specification applies to the control unit enclosed in a versatile casing (CDT(E) E) and covers its installation as well as the regulations and warnings required for correct and safe operation of the product.
  • Page 4: Operation Requirements

    CDT(E) E The product is rated for connection to single-phase AC 220–240 V, 50 Hz power mains. OPERATION Ingress protection rating against access to hazardous parts and water ingress IP30. REQUIREMENTS The product is rated for operation at the ambient temperature ranging from +1 °C up to +45 °C.
  • Page 5: Delivery Set

    CDT(E) E CDT(E) E thyristor speed regulator, hereinafter the controller, is designed for continuous smooth fan speed control. The delivery set includes: DELIVERY SET 1. Controller - 1 item; 2. Self-tapping screws with dowels: - 2 sets for wall surface mounting; - 4 sets for wall flush mounting;...
  • Page 6: Description And Design

    CDT(E) E The controller front panel is shown on fig. 4. DESCRIPTION The control knob position corresponds to the fan rotation speed. AND DESIGN The control internal design is shown on fig .5. 1 - Speed control knob; 2 - Operation lamp; 3 - Switch. 1 - Output wire clamp;...
  • Page 7: Connection To Power Mains

    CDT(E) E To connect the speed controller to the power mains follow the wiring connection diagram, CONNECTION TO Fig. 6. POWER MAINS Connection sequence: - Remove the decorative front panel and the base, Fig. A and B; - Route the wires through the ports 2, 6 in the controller casing; - Strip the wire ends 7–8 mm long;...
  • Page 8: Fault Handling

    CDT(E) E The controller starts operation immediately upon supplying the power voltage to its input. TYPICAL FAULTS If the appliance fails to operate, refer to Table 2 for troubleshooting. AND FAULT HANDLING FAULT HANDLING FAULT PROBABLE REASON Check the appliance connection Limited or (see Connection to power mains) and ensure secure contact on the...
  • Page 9 CDT(E) E WALL SURFACE MOUNTING...
  • Page 10 CDT(E) E WALL FLUSH MOUNTING...
  • Page 11: Manufacturer's Warranty

    CDT(E) E By purchasing this product the customer confirms to have read and agreed to the terms, MANUFACTURER'S rules and requirements related to operation, storage, transportation, mounting, WARRANTY adjustment, connection, maintenance and repair as well as warranty obligations with respect to this product as set forth in the manufacturer's accompanying documentation to the product.
  • Page 12 CDT(E) E NOTE: with the purpose of performing warranty servicing you please produce User Manual or other relevant substituting document and the payment document as an evidence of the purchase with indication of the sale date. The product model shall comply with that one specified in the User Manual or other relevant substituting document.
  • Page 13 CDT(E) E in case of warranty period (service life) expiry; in case of the customer's violating transportation rules assuring prevention of damaging and/or destruction of the product; in case of the customer's violating product storage rules; in case of performing unlawful actions by third persons with respect to the product; in case of force majeure (fire, flood, earthquake, war, hostilities of any kind, blockade);...
  • Page 14: Transportation And Storage Rules

    CDT(E) E TRANSPORTATION AND STORAGE RULES Transportation is allowed by any transportation vehicle provided that the product is in the manufacturer's original package. Store the delivered product in the manufacturer's original packing box in a dry ventilated premise with the ambient temperature from +5 °C up to + 40 °C and relative humidity less than 80 %.
  • Page 15 CDT(E) E WARRANTY CARD...
  • Page 16: Acceptance Certificate

    CDT(E) E ACCEPTANCE Thyristor speed controller CDT E1 CERTIFICATE CDTE E1 CDT E1.5 CDTE E1.5 CDT E2 CDTE E2 CDT E2.5 CDTE E2.5 Fan speed switch Control unit is recognized as serviceable mark the proper model Approval mark Sold (name and stamp of the trade company) Manufacturing date Date of sale...
  • Page 17 CDT(E) E...
  • Page 18 CDT(E) E...
  • Page 19 CDT(E) E...
  • Page 20 CDTE (E) v.1(1) EN...
