C.E.C. DA5 Owner's Manual page 21

BRAVO-HD Control Panel - continued -
Turning on DA5
Turning on DA5 connected via USB cable the BRAVO-
HD control panel will change to show a
In the area marked with Ⓐ click to change the sample
rate and/or bit rate to be used on Windows sharing mode.
Note: WindowsXP does not have the sample rate and
bit rate settings for sharing mode, thus Ⓐ is not showed.
In the area marked with Ⓑ the current setting and
playback via foobar2000 ASIO output are displayed. And
click to change the bit rate and buffer size.
Note: Ⓑ does not work on playback via other than
ASIO.
current setting.
Setting for sharing mode
Changing the sample rate and bits per sample on
BRAVO-HD control panel the Windows system setting on
"sound - digital output property" will change accordingly,
and vice versa.
Note: Setting 352.8kHz or 384kHz the sound from ex.
an internet browser may be unstable and noisy. In that
case set the sample rate 192kHz or lower and restart.
21
