Bravo-Hd Control Panel - C.E.C. DA5 Owner's Manual

Installation and Setup
for DSD Playback - continued -
5.5. Click "Playback - Output" at the left side tree and
select "ASIO:foo_dsd_asio" at Device. And click
"OK" to fi nish the setup.
All the installation and setup have completed.
Now foobar2000 is compatible with DSD up to 256
(11.2896MHz) and PCM up to 32bit/384kHz through DA5-
USB.
NOTE:
□ In order to avoid any interruption or affection from PC
upon listening to your desired music through ASIO at
foobar2000, set the output of reproduction to the other
than CEC DA5 HS USB Audio at Sound and Audio Device
property at your PC (refer to page 16). The volume control
and/or mute function can be operated by foobar 2000,
DA5 and/or amplifi er.
□ When you listen to the music through the other sound/
playback device than ASIO at foobar 2000 like Windows
Media Player and/or iTunes, set the output of reproduction
to CEC DA5 HS USB Audio at Sound and Audio Device
property at your PC.
20

BRAVO-HD Control Panel

To start "BRAVO-HD Audio CPL"
Click the short-cut on desktop or in the programs menu.
BRAVO-HD control panel will appear.
