KN04-00021A (Rev.1.4)
◈ Information
This Installation Guide includes a brief outline of information
necessary for product installation. For more detailed installation
information, please refer to the user manual in the enclosed CD.
The contents of the CD include the following.
1. Manual: User Manual, Code Chart, Control Commands
2. Drivers: Windows Drivers, OPOS Drivers
3. Utilities: a logo download tool
◈ Components
Cable (Option)
STP-131
AC/DC Adaptor
◈ Connecting the cables
1. Turn off the printer and the host ECR (host computer).
2. Plug the power cord into the Adaptor, and then plug the
Adaptor into the power connector of the printer.
3. Plug the cable into the interface connector.
※ Note: Use the STP-103 exclusive interface cable only.
4. Plug the drawer kick-out cable into the drawer kick-out
connector on the printer.
Power connector
Adaptor
Power cord
◈ Installing the Paper Roll
Procuct Installation CD
Procuct Installation CD
Procuct Installation CD
Paper Roll
CD
Power cord
Installation Guide
Interface connector
Drawer
kick-out
connector
Drawer
kick-out
Interface cable
cable
(Serial/Parallel)
1. Insert a new paper roll,
making sure to align it
properly.
2. Turn on the power.
3. When inserting the paper
roll, paper will be fed
automatically.
4. Open the cover.
Printer Installation Guide
THERMAL PRINTER STP-131
◈ Using the Operation Panel
• POWER (LED, GREEN)
When turning on the power, a green LED will be lit.
• ERROR (LED, RED)
When the paper is running low, a red LED blinks
When the printer is out of paper, the LED blinks quickly.
• FEED (Button)
Press the FEED button once to discharge extra paper. Holding
down the FEED button will discharge paper continuously until
the button is released.
◈ Setting the DIP switches
Changing Dip Switch settings must be done when the printer is
off. Any changes done while the printer is on will not be
processed.
• DIP Switch 1
Transmission
1-1
Speed
2400
ON
4800
OFF
9600
OFF
19200
ON
38400
ON
57600
OFF
115200
ON
Function
1-4
Print Density
1-5
Handshaking
Auto Line
1-6
Feed
1-7
Reserved
1-8
Language
• DIP Switch 2
SW
Function
2-1
Auto Cutter
2-2
Parity Selection
2-3
2-4
Reserved
2-5
2-6
Auto Cutter
2-7
Bell
2-8
Reserved
• Table1 – Parity Selection
Parity
ODD
EVEN
NONE
POWER
ERROR
FEED
1-2
1-3
OFF
OFF
ON
OFF
OFF
ON
OFF
ON
ON
OFF
ON
ON
ON
ON
ON
OFF
Bold
Normal
Xon/Xoff
RTS/CTS
With cutting
Without cutting
Combination
Completion code
code
English
Korean
ON
OFF
Full Cut
Partial Cut
Refer to the following table 1
-
Disable
Enable
Enable
Disable
-
2-2
ON
ON
OFF
Default
9600
Default
OFF
OFF
OFF
OFF
English: ON
Korean: OFF
Default
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2-3
ON
OFF
OFF
