Assembly Instructions:

1 Open Box One that contains the Frame Assembly.
2 Confirm that all parts listed for Box One are present. If any parts are missing, please call Match
Mate Tennis at 614-836-2677.
3 Attach Right Frame Leg to the right side of the U Frame using the 3/816 x 2" (HHCS) and 3/8
lock washers. Tighten the HHCS until snug. Do not fully tighten at this stage.
4 Attach the Left Frame Leg to the left side of the U Frame using the 3/816 x 2" (HHCS) and 3/8
lock washers. Tighten the HHCS until snug. Do not fully tighten at this stage.
5 Open Box Two that contains the main assembly.
6 Confirm that all parts listed for Box Two are present. If any parts are missing, please call Match
Mate Tennis at 614-836-2677.
7 While the Ball Delivery Unit is still in the box, attach the Left Handle to the Ball Delivery Unit
using the 1/4 - 20 x 3/4" button head cap screws and the 1/4 locking washer.
8 Using the Left Handle and the main assembly mounting tube, lift the Ball Delivery Unit out of the
box and set it on the foam.
white plastic head. Doing so may cause damage to the plastic housing. CAUTION: The removal of the
Ball Delivery Unit from the box requires two people.
9 Attach Right Handle using the 1/4- 20 x 3/4" button head cap screws and the 1/4 locking washer.
10 Using two people, slide the Ball Delivery Unit on the Frame Assembly Tubes. Attach the Ball
Delivery Unit to the Frame Assembly using the 3/8 – 16 x 2 1/2" (HHCS) and the 3/8 lock washers.
Tighten firmly.
11 Tighten firmly the HHCS mentioned in step 3 and 4 used to attach the
frame to the U Frame.
12 Attach the Ball Hopper to the Ball Delivery Unit using the 1/4 - 20 x 1/2" Phillips pan head screws
and 1/4 washers. CAUTION: Hopper should have a rubber O ring ball separator attached. Position the
hopper so that the ball separator is over the drop hole. If the O ring is missing or assembled incorrectly,
one will experience double firing and ball jams underneath the carousel.
WARNING: Do not lift the Ball Delivery Unit out of the box using the
left and right leg
