LAUNCH
3.2 Check before Working
Check if the big scissor platforms can work
simultaneously and smoothly.
Check if the safety ratchet cover works properly
and smoothly.
Check if the lift will stop rise automatically when
the platforms rises to the height of 1900mm
(74.8").
Check if the two small scissor tables can work
simultaneously and smoothly.
Check if the machine will stop rise automatically
when the small scissor tables rises to the height of
450mm (17.7").
Check if there is oil leaking in the oil cylinders, oil
hoses and fittings.
Check if there is air leaking in the solenoid valve,
air cylinders, pressure adjustment valves, and
fittings.
Check if the performance and sound of the motor
and gear pump are normal.
Check if the side sliding plate works normally.
Check if the emergency stop button works
normally.
Check if each part of the lift works properly.
3.3 Operating Procedure
When the vehicle driving on the lift, the speed
should be under 5km/h, and make sure that the
side sliding plate of the lift is in the locking state.
When the vehicle stops, the front wheels should
locate on the center of the turntable plate, and pull
the manual brake.
Press the big scissor UP button to raise the
vehicle
20cm～30cm(7.9"～11.8") above the
floor.
Check if the levelness of vehicle and lift is normal.
Keep pressing the UP button, and raise the
vehicle to a proper height.
TLT830WA USER'S MANUAL
Press the SAFETY LOCK button to lower the
platforms. The safety ratchets of both sides will be
engaged to ensure the safety for car servicing.
If tire changing or wheel alignment is need, press
small scissor UP button.
After servicing the vehicle, keep the work area
clear and safe before lowering lift.
3.4 Cautions for Operation
The hydraulic relief valves are well-adjusted
before leaving factory. The manufacturer will not
be responsible for any damage caused by
unauthorized adjustment.
People are forbidden under the vehicle when
lifting the vehicle.
Check the safety lock ratchets are engaged before
servicing the vehicle.
Select the suitable supporting pads on the small
scissor tables. The space between the supporting
pads should be wide enough when positioning to
obtain the largest supporting area.
When the hydraulic hoses are leaking because of
the damages, the leaking parts should be replaced
in time, and then add the oil to the required oil
level.
Once the safety ratchets are fully engaged, the
LOCK button should be released immediately. If
the Lock button is pressed for too long， too much
oil would flow back from cylinder. In this case,
the safety ratchets can not be completely released
from locked position within the set time for the
platforms to go up when the DOWN button is
pressed. This can result in no lowering action, or
lowering of only one platform, which may cause
the vehicle to fall from the lift.
8
