LED Display Definition
C Over current setting of open
limit
E Over current setting of close
limit

5. Function of external accessories

5.1 Function of photocells

Gate Status The reactions of the photocells when detecting obstacles
Closed No effect. Photocells maintain in the inactive status.
Opened Forbidden to move. If setting the automatic closing function, the door will reload automatic closing time.
Stop during moving Forbidden to move. If setting the automatic closing function, the door will reload automatic closing time.
Closing Stop closing immediately and open. If setting the automatic closing function, the door will reload automatic
closing time.
Opening Stop and wait for a next command. If setting the automatic closing function, the door will reload automatic
closing time.

5.2 Function of external push button:

Operation logic of door when press the push button: open-stop-close-stop

6. Specification

Garage Door Opener
Volt
Motor volt
Power
Force
Remote frequency
Max door area
Temperature range
Rail length
Running speed
GARAGE DOOR OPENERS USER MANUAL
Function
C1 2A as over current value of open limit
C2 3A as over current value of open limit
C3 4A as over current value of open limit
C4 5A as over current value of open limit
C5 6A as over current value of open limit
C6 7A as over current value of open limit
C7 8A as over current value of open limit
E1 2A as over current value of close limit
E2 3A as over current value of close limit
E3 4A as over current value of close limit
E4 5A as over current value of close limit
E5 6A as over current value of close limit
E6 7A as over current value of close limit
E7 8A as over current value of close limit
PG 60
AC 220V / 110V ; AC 220V / 110V ;
50Hz~60Hz 50Hz~60Hz
DC24V
72W
600N
433.92MHZ 433.92MHZ
8-10m²
o o
-20 C ~ +50 C -20
3.0m/3.3m
140mm/sec 140mm/sec
Value
1. The factory setting is "C-3"
.
1. The factory setting is "E-3"
PG 80 PG 100
AC 220V / 110V ;
50Hz~60Hz
DC24V DC24V
80W 100W
800N 1000N
433.92MHZ
10-12m² 12-14m²
o o o
C ~ +50 C -20 C ~ +50
3.0m/3.3m 3.0m/3.3m
140mm/sec
Description
PG 120
AC 220V / 110V ;
50Hz~60Hz
DC24V
120W
1200N
433.92MHZ
14-16m²
o o o
C -20 C ~ +50 C
3.0m/3.3m
140mm/sec
12
