4.7 Programmable function setting

LED Display Definition
1 Deceleration position starting
point(% full operation)
2 Open/Stop/Close/Stop
function key
3 LED light function key
4 Extra-device function key
5 Photocell function mode
6 Warning Buzzer
7 Auto-close adjustment
8 LED light function
9 Over current reaction mode
A Over current setting
11
Function Value
1-1 75%
1-2 80%
1-3 85%
90%
1-4
1-5 95%
2-0 Function off
2-1 A Key
2-2 B Key
2-3 C Key
2-4 D Key
3-0 Function off
3-1 A Key
3-2 B Key
3-3 C Key
3-4 D Key
4-0 Function off
4-1 A Key
4-2 B Key
4-3 C Key
4-4 D Key
5-0 Function off
Stop when photocell is activated
5-1
5-2 Opening phase: Keep opening when activated
Closing phase: Stop when activated.
6-1 Function off
6-2 Function on
7-1 Function off
7-2 30 sec
7-3 60 sec
7-4 90 sec
7-5 120 sec
7-6 150 sec
7-7 180 sec
7-8 210 sec
7-9 240 sec
8-1 Function off
8-2 LED light start running 1 minute
8-3 LED light start running 2 minutes
8-4 LED light start running 3 minutes
9-1 Stop when over current occur
9-2 Opening phase: Stop when over current
Closing phase: Reverse 10 cm when over current
9-3 Reverse to the end when over current.
Learning current add 0.2A as over current
1-0
2-0 Learning current add 0.4A as over current
3-0 Learning current add 0.5A as over current
4-0 Learning current add 0.6A as over current
5-0 Learning current add 0.8A as over current
Learning current add 1.0A as over current
6-0
7-0 Learning current add 1.2A as over current
8-0 Learning current add 1.4A as over current
9-0 Learning current add 1.6A as over current
9-9 Learning current add 1.8A as over current
Description
1.The factory setting is "1-3"
2. The door will reverse 2cm if over current occur in
last 10% distance.
1.The factory setting is "2-1"
1.The factory setting is "3-2"
1.The factory setting is "4-3"
1.The factory setting is "5-0 "
1.The factory setting is "6-1"
2. IF the door left opened for longer than 10mins then buzzer
start beeping and turn off until the door been closed.
1.The factory setting is "7-1"
1.The factory setting is "8-4"
1.The factory setting is "9-2"
1. The factory setting is "3-0"
