Appendix

Specifications

Television System
NTSC standard
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
43H70: 195 W (average)
55H70: 195 W (average)
61H70: 195 W (average)
Audio Power
14 W + 14 W
Speaker Type
43H70: Two 4-3/4 inches (12 cm) round
55H70: Two 6-1/4 inches (16 cm) round
61H70: Two 6-1/4 inches (16 cm) round
Video/Audio Terminals
S-VIDEO INPUT
Y : 1 V(p-p), 75 ohm, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
47 kohm)
ColorStream™ (component video) INPUT
Y : 1V(p-p), 75 ohm
P : 0.7 V(p-p), 75 ohm
R
P : 0.7 V(p-p), 75 ohm
B
AUDIO: 150 mV(rms), 47 kohm
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
4.7 kohm)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent, 4.7 kohm)
AUDIO CENTER CHANNEL INPUT
300 mV(rms) (30% modulation equivalent, 10 kohm)
44
Dimensions
43H70: Width 37-3/4 inches (959 mm)
Height 42-1/2 inches (1,080 mm)
Depth 18-7/16 inches (468 mm)
55H70: Width 46-5/16 inches (1,176 mm)
Height 53-1/4 inches (1,353 mm)
Depth 22-15/16 inches (583 mm)
61H70: Width 51-1/16 inches (1,297 mm)
Height 57-3/16 inches (1,452 mm)
Depth 25-9/16 inches (649 mm)
Mass
43H70: 133 lbs (60.5 kg)
55H70: 250 lbs (113.6 kg)
61H70: 308 lbs (139.8 kg)
Supplied Accessories
Remote Control with 2 size "AA" alkaline batteries
Optional TV Stand
43H70: ST4315, ST4305
Design and specifications are subject to change without notice.
