- Page 1 1x4 HDMI & Full 3D support over Single CAT5 Distribution Amplifier with Local Output User Manual To avoid EMI issue, complete STP Cat6 cable is strongly recommended! rev: 131028 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the SP-5105KC should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
4 HDMI enable displays through cost effective Cat-5/5e/6 cables with HDMI over CAT5 receivers (CV-735 and/or CV-715s). For convenience, SP-5105KC is also equipped a local HDMI output for monitoring. With the built in equalization, the input HDMI cable can be extended up to 20 meters (66 feet) long under Full HD, and make the overall transmission distance superior than regular HDMI splitters or matrix switches in the market. -
Page 4: Specifications
SPECIFICATIONS Model Name SP-5105KC Technical Role of usage 1x4 Distribution Amplifier Transmitter [TX] HDMI compliance HDMI Deep Color & full 3D HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color Full HD (1080p)-40m (130ft) [CAT.X]... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Front Panel POWER: bright - power on; dark - power off. SIGNAL: bright - HDMI source signal is detected; dark - no HDMI signal. Rear Panel +5V DC power: connect to 5V 4A DC interlocking power adapter HDMI INPUT: connected to HDMI source HDMI OUTPUT: HDMI output for local monitor CAT.X OUTPUT 1~4: CAT output Top Panel... -
Page 6: Switch Setting
"Auto" or "Pass-through" EDID LEARNING 1. Power up the SP-5105KC. Connect to HDMI OUTPUT with the display you want the SP-5105KC to learn its EDID. 2. To learn the display's EDID for source device connected to HDMI OUTPUT, Set SW1 to left Position. -
Page 7: Connection Diagram
CONNECTION DIAGRAM... -
Page 8: Pin Definition
PIN DEFINITION HDMI Type A (Receptacle) HDMI Pin 1 TMDS Data2+ Pin 11 TMDS Clock Shield Pin 2 TMDS Data2 Shield Pin 12 TMDS Clock– Pin 3 TMDS Data2– Pin 13 Pin 4 TMDS Data1+ Pin 14 Reserved (N.C. on device) Pin 5 TMDS Data1 Shield Pin 15... -
Page 9: Notice
NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI or HDMI display EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C &... -
Page 10: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5105KC features and specifications is subject to change without further notice.
