GoMax Electronics S-SP-3012NRT User Manual

1x2 hd-surveillance distribution amplifier
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

S-SP-3012NRT
1x2 HD-surveillance Distribution Amplifier
User Manual
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-SP-3012NRT and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics S-SP-3012NRT

Summary of Contents for GoMax Electronics S-SP-3012NRT

  • Page 1 S-SP-3012NRT 1x2 HD-surveillance Distribution Amplifier User Manual Made in Taiwan...

  • Page 2: Safety And Notice

    However, like all electronic equipments, the S-SP-3012NRT should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 3 Introduction This S-SP-3012NRT receives one SDI input, perfectly duplicates it, and re-transmits four SDI outputs for real time multi-viewing. It is a reliable video device splitting a SDI or HD-SDI video source to four HD-SDI or SD-SDI displays at the same time.
  • Page 4 Power supply 5V 4A DC Power consumption 10 Watts [max] Operation temperature 0~40C [32~104F] Storage temperature -20~60C [-4~140F] Relative humidity 20~90% RH [no condensation] 1x S-SP-3012RT / S-SP-3012NRT Package Contents 1x 5V power adapter 1x User Manual ~ 3 ~...

  • Page 5: Panel Descriptions

    Panel Descriptions Front Panel HD/SD-SDI output 1 HD/SD-SDI output 2 Rear Panel HD/SD-SDI input Red light LED — power indicator Green light LED — SDI signal indicator 5V DC power jack ~ 4 ~...

  • Page 6: Hardware Installation

    Hardware Installation 1. Connect a camera or other devices equipped with HD/SD-SDI outputs to S-SP-3012NRT 3G/HD/SD-SDI input. 2. Connect devices equipped with HD/SD-SDI inputs (e.g. monitors or video processors) to S-SP-3012NRT 3G/HD/SD-SDI outputs. 3. Plug power adapter cable into 5V DC power jack.

  • Page 7: Limited Warranty

    Limited Warranty The SELLER warrants the S-SP-3012NRT 1x2 3G/HD/SD-SDI Distribution Amplifier to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
