STOP!
BEFORE YOU CONNECT YOUR XONE:DB2 TO A COMPUTER PLEASE FOLLOW
THESE INSTRUCTIONS ON INSTALLING THE CORRECT DRIVERS FOR THE USB
SOUNDCARD.
CHECK www.XONE.co.uk/db2 FOR NEWS ON THE LATEST DRIVER VERSIONS
Software Installation (Windows XP, Vista and Windows 7)
Follow the procedure described below to install the USB audio and MIDI drivers:
1— Connect the XONE:DB2 to your mains electricity supply and switch on.
Do not connect the DB2 to the PC at this time.
2— Open the Drivers folder and run Setup.exe.
Allen & Heath
PC DRIVER INSTALLATION
3— Select your preferred language
4— Select Install the driver
XONE:DB2 User Guide
AP8640_2
5— When prompted, connect the DB2 to
the PC with the USB lead.
28
