Technical specifications:
Dimensions:
Power consumption standby:
Power consumption operational:
Power supply:
Operating temperature:
LAN connection:
Ordering code:
European standards:
EMC immunity
Radio
Telephone
Security Class
Alarm transmission
ATS classes 50136-1-1
*)
the PSTN connection complies with the TBR21 norm, but is not connected to the public telephone
exchange network. The PSTN connection generates its own telephone line signals that imitate the signals
of a public exchange network, this makes it possible to receive alarm messages from the control panel that
is connected to the PSTN connection and send them through an IP connection.
**)
see chapter 'Settings according to local requirements' for the correct settings of this device according to
the required local regulations for this specific installation. Also here you will find the settings for the Dutch
regulations according to the AL1, AL2 and AL3 norm.
The various IP transceivers are manufactured with the most modern production methods and comply with
RoHS regulations. This means that components used and the soldering procedures are lead-free.
Alphatronics b.v.
Watergoorweg 71
3861 MA Nijkerk
Telefoon: 033-2459944
Fax: 033-2453149
Web:
E-mail: info@alphatronics.nl
Service manual AlphaCom PSTN-2-IP (GPRS) transceiver
in casing : 165 x 108 x 38 mm (l x w x h).
Pcb only : 158 x 90 x 18 mm (l x w x h)
PSTN-2-IP / AlphaVision IP: 115mA.
PSTN-2-IP GPRS / AlphaVision IP + GPRS: 135mA
PSTN-2-IP / AlphaVision IP: 210mA.
PSTN-2-IP GPRS / AlphaVision IP + GPRS: 375mA
12-16 Volt dc
0- +50C
100 Mbit/s
PSTN-2-IP:
PSTN-2-IP GPRS:
AlphaVision IP:
AlphaVision IP + GPRS:
EN50130-4 2003
EN300220-3
TBR21 1998
European norm EN60950
EN50136-2-1 1998
D4, M4, T5, A3, S2, I3
www.alphatronics.nl
*)
**)
Rev. 2.2 10-07-2014
003611
003612
003609
003614
