Installation Instructions for
Tigris Mirror Round Surface (LED)
B ATH
G ENERAL RODUCT NFORMATION P I
This product is suitable for indoor locations only.
This product may be dimmed with a low voltage electronic
dimmer.
Bring power supply lines to the mirror in accordance with
local electrical codes.
This instruction shows a typical installation.

Install the Hardware

1A
BACKPLATE
2
2
1
1 Locate the studs on the wall where the mirror is going
to be mounted (Max 28-1/4" separation).
Use minimum of four slots to mount the back plate to
2
the studs with four screws and washers provided. Do
not drive the screws all the way in at this time.
C OLLECTION
:
SCREW
2
2
WASHER
2
STUD
1
C AUTION — RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
2A
POWER LINE
4
4
3 Bring the power line to one of the four circular hole on
the backplate.
While holding the back plate level and in the desired
4
position, tighten the four screws to secure it.
1
920BCTIGSD
700BCTIGRS32_-LED_
4
3
4
1.0
