Installation Instructions for
Kable Lite Sun
FUNCTIONAL ART
GENERAL PRODUCT INFORMATION:
This product is suitable for indoor dry locations only.
Installing the Lamp
1A
1
#8-32
SCREW
1
1
Remove all four #8-32 screws on Sun fixture so that it
splits into two parts.
1B
BI-PIN LAMP
2
Remove the old lamp.
1
1
2
1C
SOCKET
C AUTION: To reduce the risk of a burn or electric
shock during relamping, disconnect the power to
the fixture.
NOTE:
Use only your fingers and a soft cloth to
replace the lamp.
Use MAX 20 Watt, Bi-Pin Halogen Lamp.
Gently insert the new lamp pins into the socket holes.
3
Put the two Sun sections back together.
4
Align the screw holes, replace and tighten the four
5
#8-32 screws.
1
700KESUN_
BI-PIN LAMP
3
920KLSUNF
1.6
