Tech Lighting Tigris 700BCTIGOR24 Series Installation Instructions

Installation Instructions for
Tigris Mirror Oval Recessed
B ATH
G ENERAL RODUCT NFORMATION P I
This product is suitable for indoor locations only.
This product can be dimmed with a standard incandescent
dimmer.
The wall cavity where the Tigris Mirror will be installed must
be a minimum of 3.5" deep. Some modification to the studs
may be required.
Bring 120 Volt power supply to the mirror in accordance
with local electrical codes.
Metal bar expansion range is 24" - 42".
This instruction shows a typical installation.
Install the Hardware
1A
MIRROR OUTLINE
2
32.5"
CENTER POINT
1
Use the provided template (22.5" x 32.5") to mark the
center and outline of the mirror on the wall.
Cut out the marked outline on the wall.
2
If required, make any necessary modifications to the
3
wall studs.
C OLLECTION
:
1
22.5"
C AUTION — RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURN THE POWER TO THE
ELECTRICAL BOX OFF.
1B
5
SIDE STUD
4
Center the metal bar vertically in the oval cut out.
Extend the metal bar (maximum 42") so that the ends
5
touch the side studs.
1
920BCTOVRG9
700BCTIGOR24_
OVAL CUT OUT
METAL BAR
4
1.1
5
