Magnetek E10674-0 Quick Start Manual

E10674-0
NiMH Battery Charger
Note: All new rechargeable battery packs must be charged before usage.
•
Use of this device is intended for charging BT108-0, NiMH (Nickel Metal Hydride) rechargeable
•
batteries only.
•
Do not attempt to use this product on non-rechargeable battery packs.
•
For best performance of the battery, avoid charging the battery pack for more than 24 hours.
•
Please familiarize yourself with the instructions before attempting to use.
•
Do not dispose of a battery pack in fire; it may explode.
•
Do not charge or operate in a hazardous environment.
•
Do not short circuit battery or charger.
•
Do not attempt to charge a damaged battery.
•
Do not attempt to open the battery pack.
•
Recharging a battery only after it is fully discharged will prolong its life.
•
Avoid recharging battery when fully or near fully charged.
•
The charger unit is not intended for outdoor use. Use only indoors.
Keep the battery pack environment cool during charging operation and storage, (i.e., not in direct
•
sunlight or close to a heating source).
•
Always dispose of used batteries per appropriate regulations.
Rechargeable batteries, for longest life, should be recharged at least every 6 months even if they
are in storage.
•
Plug charger power supply in to 110 VAC 60 Hz power source. The charger will have about 14
VDC across its + and H terminals with no battery in it. The plus terminal is labeled "+" and
•
negative terminal is labeled "H".
•
Slide battery in to charger until the battery latches.
The single red LED will come on, when a battery pack is inserted in the charger and the charger
•
detects a good battery.
•
There are three charging levels: High rate: 500 mA, Top off: 40 mA and Trickle: 13 mA.
The charger automatically switches from "High rate" to "Top off" then "Trickle" charge by
•
measuring rate of change of temperature and time of charging.
If a discharged battery pack is too cold the LED will come on and it will trickle charge until the
pack warms up and then switch to high rate charge.
TC10674-0
N49 W13650 Campbell Drive
Menomonee Falls, WI 53051
Toll Free: 800-288-8178
Telephone: 262-783-3500
Website: www.magnetekmh.com

GENERAL PRECAUTIONS

CHARGING INSTRUCTIONS

For the
BT108-0 Battery
Rev. E 11/2007
