  • Page 1 R206 Smart Home Controller Smart Home Controller Manual For IPK Version 0.0.0.45 and above...

  • Page 2: Table Of Contents

    4.5 WPS Function..............................5 4.6 Indicator................................5 4.7 UPS Backup Power............................5 5. Set up R206 Smart Home Wireless Integrated Control Box..............6 5.1 Connect to the device............................6 5.2 Set up your computer (take Win XP operating system as an example)............6 5.3 Log in to the management interface of R206....................8...

  • Page 3: Introduction

    Users go out to connect to the cloud through the Internet to access the home R206 to achieve control of home appliances and at the same time, you can also watch all the changes in the home surveillance camera , easy to achieve real smart home remote control.

  • Page 4: Product Appearance

     WiFi has a total of 11 channels and supports 1 to 11 channels.  As a LoRa coordinator to avoid neighbor interference  Two RJ-45 data interfaces  Communication distance is 250 meters (depending on the specific environment)  Simple operation through third-party software control  Support Netvox Private LoRa Protocol...

  • Page 5: Installation And Preparation

    R206. Only one IP Camera, just connect one end of the network cable to the LAN port of R206 and the other end to the network port of IP Camera, so that you can form an intranet network, and the WAN port of R206 is connected to the internet network cable (there is no need to connect if it does not access internet).

  • Page 6: Wps Function

    If the connection is not established within three minutes, it will be off after 5 seconds of flashing, indicating that the WPS function is off. 4.7 UPS Backup Power R206 can be used as an backup UPS power supply for R206 to work continuously for more than 6 hours as below figure.

  • Page 7: Set Up R206 Smart Home Wireless Integrated Control Box

    Instructions for use: Connect the ⑩AC power input socket of the standby power supply into the power socket, and connect the ⑧ socket output to the DC input port of R206; press and hold the POWER button for 2-3 seconds to turn it on; then press and hold the POWER button for 2-3 seconds to turn off;...
  • Page 8 Click “Properties”and choose , and then click “Properties”.

  • Page 9: Log In To The Management Interface Of R206

    When below page shows up, select “Obtain an IP address automatically” 5.3 Log in to the management interface of R206 Open the web browser and type: http://192.168.15.1/ in the URL address bar, then press Enter or click the go button in the address bar. The following screen appears.

  • Page 10: Status

    Enter the corresponding username and password (admin: username and password are operator; client: username and password are admin), click "login", after successful, the following module page appears at the top of the page. Including state, network settings, wireless network settings, firewall, save settings, system settings, smart home, seven modules in total.
  • Page 11 (2) Click [Statistics] to view the statistics of R206, including device memory capacity, WAN data packet, LAN data packet. （3） Click [System Management] to set the user permissions, administrator permissions, NTP, Green AP, and DONS on the following pages.
  • Page 12 (4) Click [Quick Wizard], the following function interface appears, and the basic settings of the device can be made here. (5) Click [Operation Mode], the following function interface appears, you can set the operation mode suitable for your network environment here.

  • Page 13: Internet Settings

    5.3.2 Internet Settings (1) Select the [Internet Settings] module, the setup wizard screen appears, and the wide area network settings are as follows. You can select the appropriate online mode according to your environment and set parameters for different online modes. In dynamic mode, just enter the network name. In [Static (fixed IP)] mode, the user needs to manually input the IP address, subnet mask, default gateway and DNS server.
  • Page 14 In [L2TP] mode, the user sets the mode information autonomously. When the IP address mode is static, the user needs to manually enter the IP address information. When the IP address mode is dynamic, the IP address information can be obtained automatically.
  • Page 15 In [PPTP] mode, the user sets the mode information autonomously. When the IP address mode is static, the user needs to manually enter the IP address information. When the IP address mode is dynamic, the IP address information can be obtained automatically. In [3G] mode, users can plug in the 3G network card on the USB port of the gateway;...
  • Page 16 In the LTE mode, users can plug in the 4G LTE network card on the USB port of the gateway, adjust the WAN connection mode to LTE, the APN defaults to the internet, and the Dial Number to *99#. Other settings can be defaulted b. It will automatically start the 4G networking mode Unicom WAN. (The currently supported 4G LTE network card driver models are: HUAWEI EC3372h-607, HUAWEI EC3372-871, Alcatel Link Key 4G LTE IK 40).
  • Page 17 (2) Click [LAN] on the left page, and the following detailed function interface appears. Users can enable/disable and set all network functions here. (3) Click on the [DHCP Client List] on the left page to view all DHCP clients here. Users can know the assigned IP address based on the network name or MAC address.
  • Page 18 (4) Click [VPN Passthrough] on the left, and the following detailed function page appears. Users can set the VPN passthrough (enable/disable) here, including: L2TP, IPSec, and PPTP passthrough. (5) Click [Advanced Routing] on the left, where users can add/remove customized static routing rules or enable dynamic routing rule exchange protocol.
  • Page 19 (6) Click [IPv6] on the left page and the following detailed function interface appears. When the IPv6 operating mode is static, users need to manually configure the static IP address of IPv6.

  • Page 20: Wireless Settings

    5.3.3 Wireless Settings (1) Select the wireless network settings module; the following detailed function interface appears. Users can do basic wireless communication settings, such as: network name (service collection identifier) and channel. [Basic Settings] The project can be used to make simple wireless access node settings.
  • Page 21 (2) Click [Advanced] on the left. This setting page contains non-basic settings, such as beacon interval, control transfer rate, basic data transfer rate, and so on. （3）Click [Security] on the left page and the following detailed function interface appears. Under this page, the user can select the wireless network that needs to be encrypted to encrypt it.
  • Page 22 When the security mode is [OPENWEP], you need to change the network mode to 11g only, 11b only, 11 bgn mixed mode. The preset 11n only does not support OPENWEP. The setting method is as follows: When the security mode is [WPA-PSK], the setting method is as follows:...
  • Page 23 When the security mode is [WPA2-PSK] and [WPAPSKWPA2PSK], the setting method is the same as that of [WPA-PSK].If WPS is disabled. Security Mode will add Radius server options: WPA, WPA2, WPA1WPA2, 802.1X The Radius server setting method is as follows:...
  • Page 24 （4）Click [WDS] on the left, and the following detailed function interface appears. The user can choose whether to enable the wireless distributed system mode. When the wireless distributed system mode is [Lazy Mode], the user only needs to select the physical mode (including CCK, OFDM, HTMIX, GREENFIELD) and the encryption mode (NONE, WEB, TKIP, AES).
  • Page 25 When the wireless distributed system mode is [Bridge Mode], you also need to manually enter the wireless access node MAC address. When the wireless distributed system mode is [Repeater Mode], the setting mode is similar to the [Bridge Mode] setting. (5) Click [WPS] on the left, and the following detailed function interface appears.

  • Page 26: Firewall

    (1) Click [Firewall] above and the following detailed function interface appears. Users can establish firewall rules (MAC/IP/Port filtering) to protect the network from malicious attacks by Internet virus worms. The R206 gateway is disabled by default (MAC/IP/Port filtering). If you need to use internet IP...
  • Page 27 access, you need to enable (MAC/IP/Port filtering). (2) Click [System Security] on the left to protect the router or wireless access point itself by setting the system firewall. To support WAN login operations, you need to set the remote management item to the "Allow" status to support remote login.
  • Page 28 inappropriate web pages. Enter the URL to be filtered and click Add to add a new URL filtering rule. It is also able to delete the currently existing filtering rules. (4) Click [Port Forwarding] on the left to select whether to enable the virtual server settings. When users enables the virtual server, enter the IP address, port range, and comment to establish a virtual server to provide network services or to delete the virtual server of the current system.

  • Page 29: Administration

    (5) Click [DMZ] on the left, select whether to enable DMZ setting, and establish a demilitarized zone (DMZ) to distinguish between internal network and Internet. When enabled, set DMZ IP address. 5.3.5 Administration （1）Click the [Management] module on the left, and the following detailed function interface appears.
  • Page 30 In the network time setting, the user can view the current time and time zone of the gateway, the network server...etc. When the current time of the gateway is different from the local time, users can click [Host Synchronization] to synchronize the time on the computer. The NTP server is started by default, ensuring that the gateway synchronizes the network time every 12 hours.
  • Page 31 (3) Click [Setting Management] on the left, users can export the settings file to save the system settings, or import the settings file to restore the system settings, click the "View" button to select the settings file location, click on the import to restore the existing System settings. Selecting “Reset to factory default”...
  • Page 32 Then click [System Management] -> [Setting Management]. Replace the old gateway's IEEE address (that is, the IEEE address of the damaged or faulty LoRa gateway) in the old gateway input box, as shown below: Click “Replace”to see the prompt and click “Apply”to replace IEEE address as below figures:...
  • Page 33 After the replacement is successful, click [Smart Home] -> [Device List] to click the "Delete" button to delete the redundant IEEE address (00137A1000001F95) and display the replaced gateway IEEE (00137A1000001F94 as shown below).
  • Page 34 After the deletion is successful, only the LoRa gateway IEEE address that has been successfully replaced is retained, as shown in the following figure. Finally, click the restart button in the upper right corner to restart the gateway once and replace it successfully.
  • Page 35 Finally, wait for the gateway to restart the connection to the cloud. Please refer to [LoRa Smart Home Module Setup Instructions]->[Backup Restore User Data] to restore the backup data from the cloud. （4）Click [Status] on the left and users can see the status of the wireless access node.
  • Page 36 Click [Statistics] on the left to view the device-related statistics. Including the device's own （5） capacity, WAN data packets, LAN data packets, and so on. (6) Click [System Command] on the left, where users can edit the send system command.

  • Page 37: Bridge Setting

    （7）Click [SDK History] on the left to view the historical version number of the SDK. 5.3.6 Bridge Setting Please use a network cable to connect the LAN port of R206 to your computer network port, and power on the R206 with the matching switch transformer.
  • Page 38 b. When this page appears, select . Click Properties c. The following page appears, choose to get it automatically. Click OK...
  • Page 39 3) Wait for the R206 to start up (the WiFi light is on); turn on the browser and enter: 192.168.15.1 to log in to the R206 home page. 4) After logging in, click [Internet Settings], set the [Wide Area Network] online mode to: Dynamic...
  • Page 40 5) Click [Status] → [Operation Mode], select [AP Client], set [Enable NAT] to enable, and click "Apply". (Note: If you still can't modify it to AP client after confirming, it is recommended to replace Google, Firefox, and IE browser and try again. After setting, the webpage will be disconnected.

  • Page 41: Lora Smart Home Module Setup Instructions

    "WPA1PSKWPA2PSK", select Sercurity mode as: WPA2PSK in "AP Client Parameters". Note2: If you use the phone or tablet to connect R206's WiFi to the R206 homepage, WiFi will be disconnected after making some settings. Please reconnect R206 WiFi and then refresh the page.
  • Page 42 Click [Group info] to view the group information created by the device. The LoRa device has no group function. This function only supports ZigBee devices. Click [Detail] to view the details of each device. Click [Delete] to delete the corresponding device. ① The device is on the network. Before the device is deleted, the device has been powered off.
  • Page 43 (2) Device Management Click [Device Management] on the left to display the detailed function page to add new devices. 1. Add Device The product purchased by the user is not in the existing device list. Users can use this step to input the IEEE address of the device to be added to perform the screening operation.
  • Page 44 After the upgrade is completed, the Ver Date of the gateway device is displayed as the version date corresponding to the current upgrade module file. (5) Backup and Restore User Data (1.) Click [Data Management] on the left, and the following detailed function interface appears. Under this page, you can choose to back up your data to the local or cloud and restore the data to your local or cloud based on the selected backup date.
  • Page 45 When the gateway is not connected to the cloud, the user sets up the devices in the network, and after verifying that all the devices in the network are running normally, the user can choose to back up the data to the local area. In the later stage, if the device is abnormally powered off and the file is lost, the user can select the locally backed up data for restore.
  • Page 46 Netovx cloud service platform and displays it. Set up the connection between the machine and the cloud by entering the URL of the Netvox Cloud Service Platform. Note:...

  • Page 47: Set Up R206 Smart Home Wireless Integrated Control Box

    5 minutes to build a normal communication. Website setting of Netvox cloud server platform: domestic cloud platform URL: mng.netvoxcloud.com:80, foreign cloud platform URL: mngm2.netvoxcloud.com:80, to modify to other URLs may cause the gateway to connect to the cloud .

  • Page 48: Important Maintenance Instructions

    7. Important Maintenance Instructions Your device is a product of superior design and craftsmanship and should be used with care. The following suggestions will help you use the warranty service effectively. • Keep the equipment dry. Rain, moisture, and various liquids or moisture may containminerals that can corrode electronic circuits.
