Kerio Control Hardware Appliance Installation And Configuration - Kerio Control NG100W Quick Start Manual

Serial Port

4 Kerio Control Hardware Appliance Installation and Configuration

Once a suitable place has been located for the appliance and it has been plugged into a power
outlet according to the safety instructions, it is time to connect it to the network and configure
settings.
To configure the appliance:
1. Connect the antenna(s) to the hardware appliance.
2. Connect the Internet port to the Internet (e.g. DSL or Cable modem) using an Ethernet
cable.
3. Connect the LAN port to the computer that will be used to configure the appliance (see
the figures below).
4. Turn on the appliance.
USB Ports
Figure 2 Kerio Control NG300W (front + back)
Figure 4 Connecting Kerio Control NG100W to the network
Figure 5 Connecting Kerio Control NG300W to the network
Quick Installation Guide
Ethernet Ports
Wi-Fi Antennas
3
EN
