1 Purpose

This document is a quick guide for safely installing and implementing Kerio Control NG100W
and NG300W UTM appliances.

2 General Safety Instructions

During installation follow these security instructions:
• The appliance should be placed on a flat surface or securely mounted horizontally in rack
enclosure.
• Do not attempt to open or disassemble the appliance for any reason.
• Strictly follow the installation instructions (see section 4).
• Do not place the appliance near a heat source.
• Place the appliance in a ventilated space, making sure that the appliance fans and vents are
unobstructed at all times.
• Do not expose the appliance to liquids of any kind. In the event of liquid intrusion, unplug
the appliance immediately.
• Verify that the voltage and frequency of the power socket matches the values printed on
the power adapter before plugging in the appliance. Use only the power adapter supplied
with the appliance.
• Do not place any items on top of the power cable; keep the power cable away from walk-
ways or other areas where it could pose a tripping hazard.

3 Appliance Description

Kerio Control hardware appliance types:
• Kerio Control NG100W — Desktop appliance — see figure 1.
• Kerio Control NG300W — Sub-1U table mountable appliance — see figure 2.
Feature
Serial port
USB ports
Ethernet network ports
Antenna(s)
Used for connecting to a console with a serial cable
Input for USB devices
Used for connecting to the Internet and the LAN with an
Ethernet cable
Dual band antenna used for Wi-Fi
Table 1 Kerio Control Hardware Appliance Features
Power Switch
Ethernet Ports
Figure 1 Kerio Control NG100W (front + back)
Description
Serial Port
HDMI Port
USB Ports
2
Wi-Fi Antenna
