Valor PORTRAIT BSK539-549-550 Manual

CSA approved for use ONLY with Valor Arches models 539, 549 & 550
WARNING
!
A barrier designed to reduce the risk of burns from the hot viewing
glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.

Barrier Screen

A Barrier Screen is being provided to you to install on the Cast Arch Fronts
539, 549 and 550 Series. The barrier screen is designed specifi cally to
prevent any contact with the glass of the fi replace which becomes hot during
operation and remains hot when cooling.
Install the barrier screen to the Cast Arch Fronts
Snap the barrier screen's top part to the inner arch. Then slide the screen up
slightly under the hood, snap the bottom of the screen to the inner arch and
slide the screen back down so it rests on the cast fender's upper edge.
To remove the barrier screen for maintenance, push it up and pull out the
bottom then the top. Use a soft brush to clean the screen.
To clean the fi replace black matte cast front, use a soft brush. To clean the
polished cast front, use mild soap and water.
If the barrier becomes damaged, the barrier shall be replaced with the
manufacturer's barrier for this appliance.
To clean the stove glass window, refer to the owner's manual supplied with
the appliance. DO NOT clean with ammonia.
DO NOT TOUCH THE BARRIER SCREEN OR FIREPLACE WHILE DO NOT TOUCH THE BARRIER SCREEN OR FIREPLACE WHILE
THEY ARE HOT! Let the fi replace cool fi rst before cleaning it. THEY ARE HOT! Let the fi replace cool fi rst before cleaning it.
FOR S A FETY P U R P OSE , e ns ur e the ba r r ie r s c r e e n is FO R SA FE TY P U R P OS E , e ns ure t he b a r r ie r s cr een i s
re -in stal l ed on t he fi re pla c e front afte r m a i n ten an ce. r e -ins ta lle d on t he fir e pla c e fr ont a f te r m a inte na nc e .
4003623-02
© Copyright Miles Industries Ltd., 2013.
P
ORTRAIT
BSK539-549-550
Barrier Screen Kit

Installation Instructions

HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING
!
I NSTALLER
Leave this manual
with the appliance.
CO N SU MER
Retain this manual
for future reference.
Arch Fronts Barrier Screen (4003290)
Cast Arch Front 539, 549 & 550
wtih Barrier Screen
