CCD COLOR CAMERA
IK-65WDA
Please read this manual thoroughly before use,
and keep it handy for future reference.

TABLE OF CONTENTS

1. Features & Description ······································································· 4
2. Cautions ······························································································4
3. Components ························································································4
4. Part Name & Functions ······································································ 5
5. Connections and Operations ·····························································6
6. Line-Lock Phase ·················································································· 9
7. DIP Switch Settings ············································································9
8
Menu-Driven set-up ·········································································· 11
9. Remote Control ················································································· 26
10. Note on Use and Installation ··························································· 27
12. Specifications ····················································································29
13. Exterior View ·····················································································30
INSTRUCTION MANUAL
Record in space provided below the Model No. and
the Serial No. as found on the bottom of this unit.
Model No. IK-65WDA Serial No. ____________
Retain this information for future reference.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IK-65WDA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toshiba IK-65WDA

Summary of Contents for Toshiba IK-65WDA

  • Page 1: Table Of Contents

    12. Specifications ····················································································29 13. Exterior View ·····················································································30 INSTRUCTION MANUAL Record in space provided below the Model No. and the Serial No. as found on the bottom of this unit. Model No. IK-65WDA Serial No. ____________ Retain this information for future reference.

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read Instructions All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions The safety instructions and instruction manual should be retained for future reference. 3. Heed Warnings All warnings on the product and in the instruction manual should be adhered to.
  • Page 3 The lightening flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 4: Features & Description

    1.FEATURES & DESCRIPTION : (1) IK-65WDA has the following functions. (1) 133 Times Dynamic Range Toshiba developed algorithms that enable industry leading dynamic range (2) Digital Noise Reduction (“DNR”) Exclusive 3 Dimensional Digital Noise Reduction boosts S/N ratio to a incredible 53dB (3) 0.001Lux @ 1.2Minimum Illumination in slow shutter mode...

  • Page 5: Part Names And Functions

    4.PART NAMES & FUNCTIONS :...

  • Page 6: Connections And Operations

    5.CONNECTIONS AND OPERATIONS : • Power plugs of connected equipment must be disconnected before installations. • A 75-ohm coaxial cable (3C-2V or 5C-2V) is required for standard connection. • For details of wiring and operation of equipment to be connected, refer to their operation manuals.

  • Page 7: Line-Lock Control

    5.2 Line-Lock Control • Matching the vertical synchronization with the power frequency is called the Line-Lock. • This function is activated when the LINE LOCK switch is selected to ON. • When two or more cameras are switched by the video switcher for viewing by a moni- tor TV, the vertical sync.

  • Page 8: Back Focus Adjustment

    5.4 Back focus adjustment: Back focus is adjusted at the factory to accom- modate most standard lenses. If a slight adjust- ment is needed, mount the lens to the camera first. Then loosen the Focus Lock Screw. Rotate the Focus ring until a clear image is achieved. Retighten the Focus Lock Screw.

  • Page 9: Line-Lock Phase

    6.LINE-LOCK PHASE : When a video switcher switches two or more cameras, the picture may fluctuate on the video monitor due to the different AC line phase of each camera. In this case, adjust the V PHASE controller (on rear panel) to get a stable image. The camera is in the Line-Lock Mode.
  • Page 10 7.4 DN (DIP4) : MID/S.DNx32 DN mode select switch. MID (ON side) : In low light conditions the IK-65WDA automatically cuts the chroma signal and boots the gain up of the luminance by 6dB. S.DN×32 (OFF side) : Under the low light condition, the IK-65WDA automatically activates the slow shutter function.

  • Page 11: Menu-Driven Set-Up

    RS422 setting menu ADDRESS MENU PROTOCOL BIT-RATE VERSION EXIT DEFAULT MAIN menu (Except for DIP3 and DIP4 ON) GAIN MENU IDPOS EXIT CANCEL DEFAULT 001~255 TOSHIBA-P TOSHIBA-D 1200 2400 4800 9600 **************** –99~99 AUTO UPPER2/3 CENTER1/3 CENTER1/6 HIGH **************** BOTTOM LOWER2/3...
  • Page 12 ADVANCED MAIN menu (DIP3 and DIP4 ON) SHUTTER GAIN SHARPNESS MENU WHITE BAL ID. POS PTN-GEN AWB-RNG HI-RESO EXIT CANCEL DEFAULT NO-D/N S. D/N x128 –99~99 AUTO CENTER1/3 AUTO: –20~20 –99~99 –99~99 INDOOR1 INDOOR2 OUTDOOR COLOR WIDE HIGH HIGH UPPER2/3 LOWER2/3 CENTER1/6 SIDE1/6...

  • Page 13: Alc = Automatic Level Control

    8.1 Setting switches and the functions On the side panel of the cameras there are three push button switches as shown below: Switch name Select 8.2 On Screen MAIN menu (Except for DIP3 and DIP4 ON) The camera is adjusted using the On Screen Menu.

  • Page 14: Blc (Back Light Compensation)

    (4) BLC = Back light compensation Move the cursor to the position in Fig. Use the SELECT switches to select OFF, AUTO, UPPER2/3, LOWER2/3, CENTER1/ 3, CENTER1/6, LOWER1/6 Using in AES or auto iris lens, the exposure adjustment is automatically controlled so that the best picture is obtained at next monitor zone.
  • Page 15 (5) GAIN = AGC gain setting Move the cursor to the position in Fig. Use the SELECT switches to select OFF, STD, HIGH. OFF : AGC does not operate. STD : Standard position, max gain = 24dB HIGH : High-Sensitivity position, max gain = 30dB (If there is noise in low light condi- tions, set to STD.)
  • Page 16 (8) CANCEL Move the cursor to the position in fig. Press the SELECT switch to exit the menu without saving and changes. (9) EXIT Move the cursor to the position in fig. Press the SELECT switch when SAVE ALL SETTING (excluding WDR, D/N settings) is displayed to save all changes and exit the menu.
  • Page 17 HIGH : The chroma cut level is set less than 40 to 50 IRE. “HIGH” is for a brighter setting than “LOW” S.D/N (SUPER DAY/NIGHT FUNCTION) : Under the low light condition, the IK-65WDA automatically activates the slow shutter function. Practical Application...
  • Page 18 (2) WDR = Wide dynamic range function Move the cursor to the position shown in fig. Use the SELECT switches to select OFF or ON in the WDR setting. When WDR is set to ON, WDR activates au- tomatically. When WDR function is activated, the video of each field is mixed.
  • Page 19 (7) WHITE BAL (WHITE BALANCE) Move the cursor to the position shown in fig. Use the SELECT switches to select AUTO, MANUAL in the WHITE BAL settings. AUTO : The white balance is automatically adjusted corresponding to the color temperature variations on the ob- ject.
  • Page 20 (10) PTN-GEN = Test pattern generator Move the cursor to the position shown in fig. Use the L M SELECT switches to select OFF, COLOR, STEP, GRID, MULTI. : Test pattern is not displayed. COLOR : Color bar signal is displayed. STEP : Gray step signal is displayed.

  • Page 21: Dnr (Digital Noise Reduction)

    (12) DNR = Digital noise reduction Move the cursor to the position shown in fig. Use the L M SELECT switches to select LOW, HIGH, SUPER. : Standard position. HIGH : Increase the effect of DNR. SUPER : Further increase the effect of DNR. NOTE •...
  • Page 22 (14) NEXT, BACK Move the cursor to the position in fig. Press the SELECT switch, to select the last page or next page. (15) CANCEL Move the cursor to the position in fig. Press the SELECT switch to exit the menu without saving any changes.
  • Page 23 (16) EXIT Move the cursor to the position in fig. Press the SELECT switch when SAVE ALL SETTINGS is displayed to save all changes and exit the menu. (17) DEFAULT Move the cursor to the position in Fig. Press the SELECT switch to select DEFAULT, which returns the camera to its factory set- tings.
  • Page 24 (2) PROTOCOL Move the cursor to the position in Fig. Use the SELECT switches to select TOSHIBA-P, TOSHIBA-D. (3) BIT-RATE Move the cursor to the position in Fig. Use the SELECT switches to select 1200, 2400, 4800, 9600bps.

  • Page 25: Remote Control

    9.REMOTE CONTROL : RS-422 Control (Factory-setting) supported TOSHIBA-P and TOSHIBA-D. Rx Rx G Camera terminal Tx of the communication line from KBD is connected to Rx of the camera, and Tx-is con- nected to Rx-of the camera. A controllable function is as follows.

  • Page 26: Notes On Use And Installation

    NOTES ON USE AND INSTALLATION : • Do not aim the camera at the sun Do not aim the camera at the sun or point it at sun even if you are not shooting. • Do not shoot intense light Intense light such as a spotlight may cause a bloom or smear.

  • Page 27: In Case Of Problems

    IN CASE OF PROBLEMS : Condition Check Points • Are the camera and connected equipment turned on? No image • Is the iris of the lens adjusted properly? • Are cables connected correctly? • Is the monitor TV adjusted correctly? Unnatural color •...

  • Page 28: Specifications

    SPECIFICATIONS : Power Power consumption Image sensor Image pickup area Effective picture element Scanning system Scanning frequency Synchronization Resolution Minimum illuminance of subject Video output Output impedance White balance IRIS control Gain control Backlight compensation Dynamic range Lens mount Ambient temperature Ambient humidity Weight External dimensions...

  • Page 29: Exterior View

    EXTERIOR VIEW :...
  • Page 31 Memo...
