Razor GROUND FORCE GO KART V.1+ Installation Instructions

Tools Required:
A. 2.5mm Allen wrench
B. 4mm Allen wrench
C. 5mm Allen wrench
D. Phillips head screwdriver
CAUTION: To avoid potential shock or other injury, turn power switch OFF and discon-
nect charger before removing or installing the batteries. Failure to follow these steps in the
correct order may cause irreparable damage.
Step 1
Using a 5mm Allen wrench, remove the four hex
bolts that attach the seat to the frame.
Step 3
Using a Phillips head screwdriver, remove the
two screws on the steering column cover and
carefully cut the zip tie holding the wires together.
Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
( )
Not included
Figure 1
Figure 3
GROUND FORCE
THROTTLE INSTALLATION INSTRUCTIONS
Step 2
Using a 5mm Allen wrench, remove the hex
bolt on the steering wheel and place steering
wheel to the side.
Step 4
Using a 2.5mm Allen wrench loosen the set screw
located under the light indicator on the throttle
casing and remove throttle from steering wheel.
® GO KART (V.1+)
Figure 2
Figure 4
1
