- Page 1 Star Trac Fitness™ E-ST 5090 Stepper Install Guide...
- Page 2 E-ST 5090 E Series Stepper STAR TRAC E-ST STEPPER Install Guide...
- Page 3 NOTE: Inspect the shipping carton for any parts that may be missing BEFORE discarding the carton. Items can shift during trans- portation, and may be accidentally discarded with the carton. If any parts are missing, please contact Star Trac Support at 800-503- 1221.
- Page 4 Installing the Display Weldment/Neck Assembly (a) Align the Display Weldment with the base. Using the pre‐installed wire pull the Main I/O cable (large white plastic connector), power harness (small white plastic connector), and coaxial cable (black rubber cover) from the bottom through the top of the neck for mating to the display as needed. It is recommended that each wire be pulled through the neck one at a time. Take care to avoid unnecessary tension or bending of the cables. If the base will be mated with an LED Pre‐installed wire display without a PVS kit it is recommended to tuck the power harness and coaxial cable inside the neck as they won’t be used. Main I/O cable (b) Install the 4 bolts with the associated flat washers, lock washers, Coax Cable and nuts as shown. Make sure the bolts are tight. After the Neck Power Harness Assembly has been bolted in place, you can replace the shrouds that were removed as part of Step 2 above. (b) Screws M4 x 0.7 Open Display Remove (2) M4 x 0.7 screws from back of display (retain for later use) with a #2 Phillips screwdriver and separate the back of the display from the front. Installing the Display Assembly (a) Take the rear display cover and attach it to the display weldment using the supplied screws. Note that the Neck Assembly has been hidden to show the important detail but will already be attached. Install Guide STAR TRAC E‐ST STEPPER ...
- Page 5 Installing the Handrails NOTE: It is recommended that this step be performed by at least 2 people. (a) With the assistance of another person, tip the STAR TRAC E-ST STEP- PER forward and hold in place while completing the following steps.
- Page 6 (g) Repeat steps c - f for the right handrail. (h) Replace the 2 leg levelers that were removed in step b. (i) Return the STAR TRAC E-ST STEPPER to the upright position. 6. Final Assembly and Testing Check all screws to ensure they are tightened securely.
