O P E R A T I N G I N S T R U C T I O N S
VMS4200 / VMS5200
Track and trace systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VMS4200 and is the answer not in the manual?

Questions and answers

Related Manuals for SICK VMS4200

Summary of Contents for SICK VMS4200

  • Page 1 O P E R A T I N G I N S T R U C T I O N S VMS4200 / VMS5200 Track and trace systems...
  • Page 2 © SICK AG. All rights reserved O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 3: Table Of Contents

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 4 Data sheet ................98 O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 5 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 6: About This Document

    The LED is off.  O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 7: On Safety

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 8: General Safety Notes And Protective Measures

    This symbol refers to supplementary technical documentation. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 9: General Safety Notes

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 10: Dangers Connected With Handling Of The System

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 11 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 12 The device stops sending measured values and an entry is added to the error memory. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 13 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 14: Rohs Directive

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 15: System Description

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 16: Structure Of The Volume Measurement System

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 17 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 18 Voltage supply unit with fuse modules Ethernet switch O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 19: Expanding The System With A Reading Station

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 20: Operating Principle Of The Volume Measurement System

    Object detection via a trigger signal also reliably detects very flat objects. Note O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...
  • Page 21 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 22: Calculating The Volume

    Fig. 14: Measuring point determination by LMS4xxx O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 23 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 24: Data Processing And Data Output

    Fig. 18: Data processing (LFT mode) O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 25 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 26: Nominal Value Conditions

    Table 3: Measuring range and scale interval for VMS5200 (operating condition 2) O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 27 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 28 Table 9: Measuring range and scale interval for VMS5200 (operating condition 8) O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 29: Dynamic Scale Value Switchover

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 30: System Requirements

    The measuring objects must not be exposed to any vibrations. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 31: Mounting Requirements

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 32 O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 33 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 34: Officially Verifiable Operation

    The SIM2000 system controller type label is affixed to the metrology information label. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 35 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 36 LMS4xxx O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 37 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 38: Security Seal

    Security seal on all plug connectors for the electrical connections. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 39 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 40 Security seal on the male connectors. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 41: Sd Card With Alibi Memory

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 42 Fig. 33: Calibration switch for interlocking the metrological software parameters O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 43: Lft Display

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 44 Fig. 36: LFT display – display of the firmware versions O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 45 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 46: Test Instructions For Market Surveillance

    Note for billing. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...
  • Page 47 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 48 Press the HISTORY button to call up current and any older version statuses of a component. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...
  • Page 49 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 50: Status Indicators

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 51: Interfaces

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 52: Mounting

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 53: Assembling The Profiles Of The Telescopic Tube

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 54 Check the device is firmly attached. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 55: Mounting The Measuring Wheel Encoder

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 56: Mounting The Photoelectric Retro-Reflective Sensor And Reflector (Optional)

    Fig. 49: Photoelectric retro-reflective sensor and reflector O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 57: Mounting The Cabinet

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 58: Dismantling The Measurement System

    Verweisquelle konnte nicht gefunden werden.. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 59: Electrical Installation

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 60 ES1 EN 60368-1). O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 61: Connection Overview

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 62: Connecting To The Voltage Supply

    Table 12: Pin assignment of the -X100 terminal block on the SIC2000 O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 63: Connection For The Ethernet Switch (Set Up At The Factory)

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 64: Connecting The Volume Measurement Devices

    Table 15: Connection for LMS4xxx slave O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 65: Connecting The Lft Display

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 66: Connection For The Measuring Wheel Encoder

    Table 17: Connection for the measuring wheel encoder O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 67: Connection For The Photoelectric Retro-Reflective Sensor (Optional)

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 68: Connecting To The Customer Interface

    Ethernet or Gbit interface. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 69: Commissioning

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 70: Configuring The System With Sopas

    PC. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 71 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 72: Allocating Ip Addresses

    If not, change the IP address of the configuration PC accordingly. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 73 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 74 O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 75 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 76 The TCP/IP Settings window opens. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 77 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 78: Opening The Configuration Interface

    Online appears in the tile. The LED lights up green. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 79 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 80: Logging Into The Device

    2. Select a directory and file name and then confirm your choice. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 81: Maintenance And Repairs

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 82: Monitoring And Cleaning Work

    O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 83: Visual Inspection

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 84: Cleaning The Volume Measurement Devices

    Fig. 61: Cleaning the front screen of the volume measurement device O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 85: Checking The Measuring Wheel Encoder Components

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 86: Cleaning The Photoelectric Retro-Reflective Sensor

    Check the filter mats at regular intervals and replace if necessary. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 87 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 88: Replacing Components

    Contact the manufacturer if a repair is needed. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 89 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 90: Replacing The Measuring Wheel Encoder

    Screw the M12 plug connector onto the male connector on the measuring wheel encoder. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...

  • Page 91: Replacing The Photoelectric Retro-Reflective Sensor

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 92: Fault Diagnosis

    Table 23: LED fault indication in the event of a photoelectric retro-reflective sensor fault O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 93: Troubleshooting For The Sic2000

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 94: Checking The Incremental Encoder

    Table 25: Fault situation: Checking the incremental signals on the controller O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 95: Checking Can Cabling

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 96: Faults During Operation

    Table 28: Fault situation: ‘Sys RDY’ LED does not light up O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...

  • Page 97: Detailed Fault Analysis

    8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...

  • Page 98: Appendix

    DC 24 V ± 10%/ ~ 60 W type. power consumption O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK...
  • Page 99 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 100 The customer receives the certificate after a successful conformity assessment. O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system...
  • Page 101 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
  • Page 102 DISPOSAL O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system 8022965/2018-08-16|SICK Subject to change without notice...
  • Page 103 8022965/2018-08-16|SICK O R I G I N A L O P E R A T I N G I N S T R U C T I O N S | VMS4200 / VMS5200 volume measurement system Subject to change without notice...
