- Page 1 ® R900 IoT Gateway Installation Supplement Page 1...
-
Page 2: Table Of Contents
Contents Overview................................3 Scope ................................3 Configurations ..............................4 Components ..............................5 Required Installation Equipment ........................6 Installing the UPS.............................. 7 Installing the PoE Injector ..........................8 Installing the Ethernet Surge Protector ......................10 Installing the Gateway ............................ 11 Installing the GPS Antenna ..........................12 Installing the RF (900 MHz) Antennas ...................... -
Page 3: Overview
Overview The R900 IoT Gateway is a LoRaWAN IoT gateway that supports the full range of LoRaWAN channels. The hardware architecture supports two Neptune RF antennas, a GPS antenna, direct DC input power or Power over Ethernet (PoE), and backhaul options including copper Ethernet and 3G/4G wireless. The gateway model specified for deployments is the TEKTELIC Kona Mega T0004250. -
Page 4: Configurations
Configurations It is recommended to install the gateway at the top of the tower, although it can also be installed at the bottom as shown in the following figure. The selected options for powering and cabling from the required materials list will depend on the selected configuration. -
Page 5: Components
13866-001 10-METER POWER CORD 13818-001 N-CONNECTOR FOR GPS COAX ASSEMBLY 13841-001 ETHERNET SURGE PROTECTOR ALL ITEMS IN THIS TABLE ARE INCLUDED WITH EACH R900 IoT GATEWAY PART NO. DESCRIPTION QTY. 13795-001 BRACKET, POLE AND WALL MOUNT w/ MTG. SCREWS, KONA... -
Page 6: Required Installation Equipment
Required Installation Equipment Item Description Toolkit Medium, flat-head, Phillips, etc. Various screwdrivers Cordless electric drill with assorted bits Crescent wrench Standard socket wrench set Hammer Channel Locks T27 Torx Pin-Head Tool PPE as required Weatherizing kit Scotch WK-101 Weatherizing cable connections Corrosion inhibitor NOCO Company's NCP-2 or Apply to battery terminals... -
Page 7: Installing The Ups
Installing the UPS 4. Run the DC cable through the pre-punched ¾” (19 mm) hole at the bottom of the UPS Note: Before installing the UPS, a quick disconnect enclosure via the cable gland. method for AC power should be installed near the UPS at the AC Input by a licensed electrician. -
Page 8: Installing The Poe Injector
Installing the PoE Injector b. If pole mounting, first secure the PoE injector to the base of the mount. Required Items PoE injector with grounding cable and • Ethernet cable covers Ethernet cable with 2x RJ45 connectors • 2x adjustable wrench •... - Page 9 Assemble the DC power cord with the DC 6. Run the Ethernet cable through the power connector (included) for the PoE watertight connector before terminating it. injector. 7. Terminate the Ethernet cable. 8. Plug the Ethernet cable into the PoE injector’s DATA PWR OUT port.
-
Page 10: Installing The Ethernet Surge Protector
4. Run the Ethernet cable coming from the indoor networking equipment through the watertight connector to one side of the surge protector. 5. Run the Ethernet cable coming from the R900 IoT Gateway or PoE injector through the Page 10... -
Page 11: Installing The Gateway
bolts and tightening the bolts. Orient the Installing the Gateway gateway with connector bulkheads facing downward toward the earth. Before starting, it is recommended to review the mounting hardware table, the Kona Mega Gateway 4. Insert and tighten two additional site- User Guide and the Kona Mega Quick Start Guide supplied M8 bolts through the holes at the referenced in the appendix. -
Page 12: Installing The Gps Antenna
8. Connect the coax to the GPS port on the Installing the GPS Antenna gateway. Care should be taken not to The diameter of the mounting pole supported is 1 damage the RF connectors while tightening. 5/8” to 2 3/8” (40-60 mm). Care should be taken not to exceed the bend Required Items radius of the coax. -
Page 13: Installing The Rf (900 Mhz) Antennas
Installing the RF (900 MHz) Antennas Required Items 4. Attach the coax cables to the RF antennas. 2x RF Antennas Care should be taken not to damage the RF • 2x pairs of antenna mounting brackets connectors while tightening. Care should also •... -
Page 14: Installing The Cellular Antenna
1. Use the mounting hardware from the Installing the Cellular Antenna To mount the cellular antenna externally: Required Items mounting kit to secure the antenna in place Torque wrench for the N-Type Connector • (see the mounting guide in the appendix for •... -
Page 15: Appendix A - Reference Documents List
Appendix A - Reference Documents List Document Purpose Kona Mega Quick Start Guide Gateway installation and maintenance Kona Mega Gateway User Guide Gateway installation and maintenance TEKTELIC Kona -PoE Powering Gateway and PoE reference Gateway Solar Power Guide Solar powering reference Gateway Battery Back-up Powering Guide Battery backup power reference Microsemi PD-9501GO-48VDC User Guide... -
Page 16: Appendix B - Mounting Hardware
Appendix B - Mounting Hardware Component Installation Option Recommendations Comments Wall Mount 4x 5/16" bolts. Adhere to national and local codes and regulations. Large Pole 2x site-supplied Neptune stainless Not Included steel bands (PN: 13089-001) or other ¾-inch wide stainless-steel straps for poles larger than 4"... -
Page 17: Appendix C - Specifications
Appendix C - Specifications TEKTELIC Gateway Specifications Input power (-48)VDC or PoE++ (803.3bt) Power consumption <40 Watts Operational Temperature (-40) to +55 ºC Operational Humidity 10% to 100% condensing Weather Rating IP67 Size 222.2x267.6x101 mm Weight 5 Kg Ethernet Interface RJ-45 GPS Interface N-Type... - Page 18 UPS Specifications AC Input Voltage 90V-305Vac AC Input Frequency 47/63 Hz Input Plug Type 3 prong grounded Input Cable Length DC output Power 150 Watts DC Output Voltage 45-50V DC output Connector 2 position screw terminal Alarms Battery On, Battery Low, Battery Fail, Battery Missing Battery Type Lead acid...
- Page 19 PoE Injector Specifications Data rates 10/100/1000 Mbps PoE Output Power 60W @ 50-57VDC PoE pin assignment 4/5 (+), 7/8 (–), 1/2(–), 3/6(+) Standards Compliance IEEE 802.3af (PoE, PoH Type1) IEEE 802.3at (PoE+ including 2-event, PoH Type 2), RoHS Compliant, WEEE Compliant, CE DC Input Power 36 to 60 VDC Dimensions...
-
Page 20: Appendix D - Rf Antenna Best Practices
Appendix D - RF Antenna Best Practices The following section highlights best practices for installing the antennas: Mount antennas as high as possible, in a location which provides clear line-of-sight (LOS) to connecting devices. Note: o Nearby objects, including the antenna’s supporting structure can change the antenna pattern and cause areas of limited coverage o Water towers often block the line of sight path between antenna and the connecting devices, reducing coverage in some directions. -
Page 21: Appendix E - Feed Line Requirements
If the condition persists, contact customer support. PSD R900 IoT GATEWAY INSTALLATION SUPPLEMENT 10.19 © Copyright 2019, Neptune Technology Group Inc. Neptune is a registered trademark of Neptune Page 21 Technology Group Inc. LoRa and LoRaWAN™ are registered trademarks or service marks of Semtech Corporation and/or its affiliates.
