Summary of Contents for Mira Bijou
- Page 1 BIjoU and mIra ordo thermostatIc mIxers InstallatIon & User GUIde These instructions must be left with the user.
-
Page 2: Table Of Contents
Specifications and temperature control. Pressures temperatures the mira Bijou has a 300 mm clear glass storage thermostatic shut-down shelf and is supplied complete with mira l14a shower Fittings. connections the mira ordo has a 235 mm black glass storage... -
Page 3: Guarantee
Guarantee For domestic installations, mira showers guarantee the mira Bijou and mira ordo against any defect in materials or workmanship for a period of three years from the date of purchase (shower fittings for one year). For non-domestic installations, mira showers... -
Page 4: Pack Contents
1 x Fixing Bolt 1 x spacer 1 x 4 mm hexagonal Key 1 m6 x 5 mm Grubscrew 1 x mira Bijou or mira ordo thermostatic mixing Valve 2 x concealing Plates 2 x compression nuts 2 x olives... -
Page 5: Safety Warnings
WarnInGs For Type 2 Valves, the supply conditions specified mira thermostatic mixers are precision engineered in section: ‘Type 2 Valves - Application’ take and should give continued safe and controlled precedence over the operating parameters which performance, provided: follow. -
Page 6: Dimensions
Dimensions 300 mm - mira Bijou 235 mm - mira ordo 113 mm 65 mm 17 mm 153 mm 39 mm see Note! below allow 100 mm allow 100 mm minimum to Wall minimum to Wall Note! If you are retro-fitting your mixing valve onto existing pipework, an Adjustable Elbow Pack is available if required, refer to section: ‘Accessories’. -
Page 7: Installation
6. decide on a suitable position for the mixer. InstallatIon the position of the mixer and the shower Fittings must provide a minimum gap of 25 mm Suitable Plumbing Systems between the spill-over level of the shower tray/ bath and the showerhead (refer to illustration). Gravity Fed: this is to prevent back-siphonage. -
Page 8: Installing The Thermostatic Mixer
Installing the Thermostatic Mixer 3. For solid walls drill the holes for the backplate with a 6 mm drill and insert the wall plugs 1. the thermostatic mixer can be installed with (supplied). For other types of wall structure rear or rising supply inlets. decide on the most alternative fixings may be required (not appropriate method for your installation, and if supplied). - Page 9 6. Reversed Inlet Supplies Only: 7. remove the backplate from the mixer by loosening the grubscrew with a 2.5 mm Using a suitable tool, carefully remove the hexagonal key (supplied). plug cap from the centre of the sealing plug to reveal keyway. 8.
- Page 10 11. Fit the compression nuts and olives onto the 16. Fit the shower fittings, refer to your shower pipework. fittings installation and user guide for instructions. 12. Align the mixer with the pipework and fit onto the backplate. Note! For user comfort on high pressure systems, a 12 litre/minute flow regulator Important! make sure that the hot and cold (supplied) can be fitted inside the outlet nipple.
-
Page 11: Commissioning
5. Insert the 2.5 mm hexagon key into the centre commIssIonInG of the spindle and engage with the recessed temperature adjusting screw. Maximum Temperature Setting 6. rotate the hexagon key until the required maximum temperature is obtained at the Before using the shower the maximum temperature shower. -
Page 12: Operation
Mira Bijou and Mira Ordo are thermostatic mixing valves which have a single sequential control knob for on/off and temperature control. the control knob operates anti-clockwise in the following sequence: • • • cold • Warm • maximum Preset temperature... -
Page 13: User Maintenance
Lubricants User maIntenance silicone based lubricants must only be used on If you require a mira trained service engineer or the rubber seals. agent, refer to section: ‘Customer Services’. Caution! oil based or other lubricant types may cause rapid deterioration of seals. -
Page 14: Type 2 Valves
2 Valves temperature and pressures. make sure are as follows: that they are within valve specifications. models designation measure and record blend mira Bijou, mira ordo lP-s, hP-s temperature and flow rate. (Tb) the permitted application details are: operating... -
Page 15: Spare Parts
Bearing 1663.158 assembly 1663.155 outlet nipple Filter Pack (x2) 1663.232 Control Knob Assembly (Bijou) 1672.030 Control Knob Assembly (Ordo) 1663.159 Seal Pack - components identified ‘A’ 1663.161 Component Pack (valve) - components identified ‘B’ (also includes 2.5 mm hexagonal Key) 1663.162 Screw Pack - components identified ‘C’... -
Page 16: Customer Service
Our Service Force is available to provide a quality service of limescale. at a reasonable cost. You will have the assurance of a Mira Damage or defects if the product is taken apart, repaired or trained engineer/agent, genuine Mira spare parts and a modifi...
