Linkage Test - An easy way to confirm proper operation after installation is to perform the
following quick linkage test. With key OFF, push the manual throttle lever to ¾ open
position. Then take the black knob on servo motor and slowly wind the knob in a counter
clockwise, then clockwise direction. As you do this, the engine throttle arm will slowly open
and close. This should happen very smoothly and in no place shall the cable "catch" or
"hook" which will cause the servo to hunt. If the cable does "catch", adjust servo & cable to
eliminate this problem.
If the cable comes into any interference with the fuel rail, decorative engine cover or
anything that causes this problem, adjust motor and cable accordingly.
The brass L bracket on the throttle linkage must be able to swivel freely for system to work
smoothly.
IMPORTANT: - Make sure all wires are tied away from hot or moving parts and there
is adequate clearance.
- The manual throttle on your boat should operate and feel the same
as before the PerfectPass was installed, or you may have to adjust
hex nut.
If you have re-installed a decorative engine cover, with key "OFF" push the throttle down to
full open and back to neutral. At no point should the PerfectPass cable "hook" or "jam".
(Never tie wrap on restrict the PerfectPass cable from free movement).
