Deleting/Editing Names – As you scroll through list of names, instead of pressing UP key to
select that name, press the DOWN key to edit or delete.
4.

SYSTEM INFO

Press UP Key to enter. The Software Version, Battery Volts and system hours can be found
here.
5.

DEVICE TEST

Press UP Key to enter. Here you can test the Rope Switch AND test Servo Motors, etc.
Rope Switch Test – This feature allows you to test the rope switch to be used prior to a
tournament and will appear as [ROPE SWITCH TEST]. Pull hard on the rope to close switch
and it will change to [ROPE SWITCH ON] and there will be an audible beep to confirm proper
operation. Since it takes 250 pounds of force to trigger a Slalom Switch, it is very difficult to
do. The easiest way to confirm operation is to ski with it and watch the
upper right corner. This symbol will turn into
Servo Motor Test – After Rope Switch Test, Servo Test will appear as follows: (See Servo
Motor Phase Test video at
6. USER SETTINGS/ENGINE SELECTION (Tach Signal)
Switching display to Metric (KPH <>MPH).
Engine Set Up – Here you can INVERT the RPM or change to V6, etc. (Contact PerfectPass for
assistance).
Press MENU to view next screen.
Water Temp only available on
paddlewheel equipped boats.
when the switch is activated.
www.perfectpass.com "Support".
symbol in the
23
