Summary of Contents for DURKOPP ADLER 755
- Page 1 755/756 Additional Instructions Tape feeder...
- Page 2 IMPORTANT READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE All rights reserved. Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents, including extracts, is prohibited without the prior written approval of Dürkopp Adler AG. Copyright © Dürkopp Adler AG 2018...
-
Page 3: Table Of Contents
Assembling and connecting the tape feeder ........ 4 Setting the height of the tape feeder ..........9 Aligning the tape roll holder ............10 Inserting the reinforcement strip ..........11 Setting up the tape feeder in the software ........13 Additional Instructions 755/756 - 00.0 - 10/2018... - Page 4 Table of Contents Additional Instructions 755/756 - 00.0 - 10/2018...
-
Page 5: General Information
0755 512514 Guide carrier 0755 590914 Roll holder 9710 063411 Magnet valve 0798 120401 Cord clip 0755 512613 Suction pipe 0755 400990 Bracket 0755 591714 Dual SM card 0791 755700 EN Additional Instructions Additional Instructions 755/756 - 00.0 - 10/2018... -
Page 6: Tape Feeder
2. Use the connecting piece to connect pneumatic hose (3) with the transparent hose of the tape feeder. • gray: Press on/loosen tape 3. Remove the fabric sliding plate. 4. Swivel up the machine head. Additional Instructions 755/756 - 00.0 - 10/2018... - Page 7 (7) when you fold down the machine head. 8. Guide pneumatic hoses (1), (2) and (3) under the machine head and fix them in place at the existing cables using cable ties. Additional Instructions 755/756 - 00.0 - 10/2018...
- Page 8 (3) - Pneumatic hose (12) - CAN cables 11. Assemble the circuit board (10) and connect it to the control using the CAN cables (12). 12. Assemble the valves (11) on top of the valve block. Additional Instructions 755/756 - 00.0 - 10/2018...
- Page 9 14. Assemble the tape roll holder (14). 15. Fit the pneumatic hose (13) for the tape puller and lay it below the machine. 16. Use cable ties and clips to fix the pneumatic hose (13) in place. Additional Instructions 755/756 - 00.0 - 10/2018...
- Page 10 19. Lay the pneumatic hose (13) through the machine arm from below. 20. Use a Y-connection (15) to connect the pneumatic hose (13) to a hose of valve X814. 21. Place the valve cover. 22. Swivel down the machine head. Additional Instructions 755/756 - 00.0 - 10/2018...
-
Page 11: Setting The Height Of The Tape Feeder
• Set the tape feeder lower: Increase the screw-in depth of the threaded pins (3) 5. Tighten the screws (1). Make sure that the set height of the tape feeder does not shift. 6. Tighten the screws (2). Additional Instructions 755/756 - 00.0 - 10/2018... -
Page 12: Aligning The Tape Roll Holder
(3) into the guide rail (5). 2. Position the advancing device (4) below the guide rail (5). Make sure the loose reinforcement tape is not obstructed by the advancing device (4). Additional Instructions 755/756 - 00.0 - 10/2018... -
Page 13: Inserting The Reinforcement Strip
Ensure that the disk (5) clamps the tape roll securely. 4. Feed the reinforcement strip (4) from bottom to top through the advanc- ing device (3). 5. Insert the reinforcement strip (4) into the guide (1) behind the tape monitor (2). Additional Instructions 755/756 - 00.0 - 10/2018... - Page 14 Fig. 11: Replacing the suction pipe To allow for an easier insertion of the reinforcement strip, you can replace the suction pipe (8) with the flat suction pipe that is included in the kit. Additional Instructions 755/756 - 00.0 - 10/2018...
-
Page 15: Setting Up The Tape Feeder In The Software
2. Open the menu Program parameters > Automatic tape feeder to set the tape length at seam beginning and seam end as well as the transport clamp speed during transport ( Operating Instructions). Additional Instructions 755/756 - 00.0 - 10/2018... - Page 16 Tape feeder Additional Instructions 755/756 - 00.0 - 10/2018...
- Page 18 DÜRKOPP ADLER AG Potsdamer Str. 190 33719 Bielefeld Germany Phone: +49 (0) 521 925 00 Email: service@duerkopp-adler.com www.duerkopp-adler.com...
